Infineon FF300R12KE3 IGBT Module: Comprehensive Technical Guide for Industrial Automation Applications
Infineon FF300R12KE3 IGBT Module
High-Performance 3-Phase IGBT Power Module for Industrial Automation and Power Conversion Systems
Product Overview
The Infineon FF300R12KE3 is a premium 3-phase IGBT (Insulated Gate Bipolar Transistor) module designed specifically for high-power industrial applications. This advanced power semiconductor module represents the cutting edge of power electronics technology, offering exceptional efficiency, reliability, and performance in demanding industrial environments.
As a key component in PLC industrial automation systems, the FF300R12KE3 enables precise control of high-power motors, drives, and power conversion equipment. Its robust design and advanced thermal management make it ideal for applications requiring high switching frequencies and efficient power handling.
Product Demonstration Video
Technical Specifications
| Parameter | Specification | Value |
|---|---|---|
| Module Type | 3-Phase IGBT Module | Half-Bridge Configuration |
| Collector-Emitter Voltage (Vces) | Maximum Voltage Rating | 1200V |
| Collector Current (Ic) | Continuous Collector Current | 300A |
| Pulsed Collector Current | Maximum Pulse Current | 600A |
| Gate-Emitter Voltage | Maximum Gate Voltage | ±20V |
| Power Dissipation | Maximum Power Handling | 1.45kW |
| Module Dimensions | Physical Size | 106.4mm Length |
| Mounting Style | Installation Method | Screw Mount |
| Operating Temperature | Temperature Range | -40°C to +150°C |
| Isolation Voltage | Electrical Isolation | 2500V RMS |
Key Features and Benefits
Advanced Power Management
The FF300R12KE3 features exceptionally low switching losses, enabling higher efficiency in power conversion applications. This results in reduced energy consumption and improved system performance across various industrial applications.
Robust Thermal Performance
With advanced thermal management capabilities, this IGBT module can handle high power dissipation (1.45kW) while maintaining optimal operating temperatures. The screw mount design ensures excellent heat transfer to cooling systems.
High Reliability Design
Built with Infineon's proven semiconductor technology, the FF300R12KE3 offers exceptional reliability and long service life, making it suitable for critical industrial applications where downtime is not an option.
Compact Form Factor
Despite its high power handling capabilities, the module maintains a compact design (106.4mm length) that allows for space-efficient integration into industrial control cabinets and power electronics systems.
Industrial Applications
Motor Drives and Inverters
The FF300R12KE3 is ideally suited for high-power motor drives, including industrial pumps, compressors, and conveyor systems. Its 3-phase configuration makes it perfect for variable frequency drives (VFDs) and servo drives.
Power Conversion Systems
This module excels in power conversion applications such as uninterruptible power supplies (UPS), solar inverters, and welding equipment, where efficient power handling is critical.
Industrial Automation
In PLC-based industrial automation systems, the FF300R12KE3 provides reliable power switching for control circuits, heating elements, and high-power actuators.
Renewable Energy Systems
The module's high efficiency makes it suitable for renewable energy applications, including wind turbine converters and grid-tied solar inverters.
Installation and Integration
Mounting Requirements
The FF300R12KE3 utilizes screw mount installation, requiring proper torque specifications and thermal interface materials for optimal heat dissipation. Proper mounting ensures maximum thermal performance and electrical isolation.
Electrical Connections
The module features clearly labeled terminals for DC bus connections, output phases, and gate driver connections. Proper wiring practices and appropriate cable sizing are essential for reliable operation.
Cooling Considerations
Effective cooling is crucial for maximizing the module's performance. Recommended cooling methods include forced air cooling, liquid cooling, or heat sink mounting with appropriate thermal paste application.
Gate Driver Requirements
The module requires proper gate driver circuitry with ±20V gate voltage capability. Proper gate resistor selection and drive circuit design are essential for optimal switching performance and EMI reduction.
Purchase Information
For authentic Infineon FF300R12KE3 IGBT modules with guaranteed quality and manufacturer warranty, visit our official product page:
Purchase FF300R12KE3 ModuleOur official store at koeed.com offers genuine Infineon products with complete technical support and warranty coverage. We ensure that every FF300R12KE3 module we supply meets the highest quality standards and comes with proper documentation.
When purchasing from our official product page, you receive:
- Genuine Infineon FF300R12KE3 modules
- Full manufacturer warranty
- Technical documentation and datasheets
- Application support and integration guidance
- Fast shipping and reliable delivery
Frequently Asked Questions (FAQ)
The FF300R12KE3 can operate at switching frequencies up to 20kHz, making it suitable for most industrial applications including motor drives and power converters.
The module requires active cooling. Recommended methods include forced air cooling with appropriate heat sinks or liquid cooling systems for high-power applications. Proper thermal interface material should be used between the module base plate and heat sink.
Yes, the module can be used in parallel configurations for higher current applications. However, proper current sharing techniques and thermal management must be implemented to ensure balanced operation and reliability.
The module requires a gate driver with ±20V capability. Typical recommended gate voltage is +15V for turn-on and -5V to -15V for turn-off to ensure reliable switching and prevent false triggering.
Absolutely. The FF300R12KE3 is specifically designed as a 3-phase IGBT module, making it ideal for three-phase motor drives, variable frequency drives (VFDs), and other three-phase power conversion applications.
You can purchase authentic Infineon FF300R12KE3 modules from our official store at koeed.com/products/new-1pc-infineon-ff300r12ke3-module. We guarantee genuine products with full manufacturer warranty and technical support.
Technical References and Resources
Industry Standards Compliance
The FF300R12KE3 complies with relevant international standards for power semiconductor devices, including IEC standards for industrial equipment and safety requirements.
Design Considerations
When designing with the FF300R12KE3, consider proper snubber circuits for voltage spike suppression, appropriate gate drive circuitry, and comprehensive thermal management solutions.
Reliability Data
Infineon provides extensive reliability data including MTBF (Mean Time Between Failures) calculations, thermal cycling capabilities, and lifetime predictions under various operating conditions.
Application Notes
Comprehensive application notes are available covering topics such as paralleling techniques, protection circuit design, EMI reduction strategies, and system integration best practices.
Conclusion
The Infineon FF300R12KE3 represents a high-performance solution for demanding industrial power applications. With its 1200V/300A rating, advanced thermal management, and robust design, this IGBT module delivers reliable performance in the most challenging industrial environments.
For industrial automation engineers, power electronics designers, and system integrators, the FF300R12KE3 offers a perfect balance of performance, reliability, and efficiency. Its compatibility with modern control systems and ability to handle high switching frequencies make it an excellent choice for next-generation industrial applications.
To obtain genuine FF300R12KE3 modules with full technical support and warranty, visit our official product page at https://koeed.com/products/new-1pc-infineon-ff300r12ke3-module.
