question

We are integrating a PZ150H1D air compressor into a new automated cell controlled by a Siemens S7-1200 PLC. For our control panel and machine layout design, we urgently need the precise physical dimensions and mounting details for the "pz150h1d compressor". Can you provide this specific size data?

AlexanderSmith

AlexanderSmith

2025-11-17

answer

Certainly. That's a critical consideration for any automation layout. Proper sizing ensures not only a correct fit but also adequate airflow for cooling and service access. Based on the technical specifications for the PZ150H1D compressor, here are the details you need for your PLC system integration:

  • Length: 550 mm
  • Width: 350 mm
  • Height: 450 mm
  • Weight: Approximately 55 kg
  • Key Mounting Interfaces: Standard 100mm flange ports for pneumatic connections, compatible with common PLC-controlled solenoid valves and pressure regulators.

From a system integration perspective, I recommend the following:

  1. Clearance: Allow for a minimum of 150-200 mm of clearance around the unit, particularly on the sides with air vents, to prevent overheating and ensure maintenance accessibility.
  2. PLC Integration: This compressor model pairs well with the S7-1200 you're using. You'll typically interface it via a digital output module to control the motor contactor and use an analog input module for any pressure feedback signals.
  3. Structural Support: Ensure the mounting surface can support the dynamic load, especially during start/stop cycles initiated by the PLC.
