BC10-QF5.5-AP6X2 Capacitive Proximity Sensor: Complete Technical Guide and Applications
BC10-QF5.5-AP6X2 Capacitive Proximity Sensor
Professional-grade capacitive proximity sensor for industrial automation applications
Product Overview
The BC10-QF5.5-AP6X2 is a high-performance capacitive proximity sensor manufactured by Turck, designed for reliable object detection in demanding industrial environments. With model number 2620117, this sensor features a 10mm sensing range and compact 5.5mm thick rectangular body, making it ideal for space-constrained applications in PLC-based automation systems.
Technical Specifications
| Parameter | Specification | Details |
|---|---|---|
| Model Number | 2620117 | Turck product identification |
| Sensing Range | 10 mm | Rated switching distance |
| Body Thickness | 5.5 mm | Rectangular body design |
| Operating Voltage | 10-30 VDC | Wide voltage range for flexibility |
| Output Function | NO Contact, PNP | Normally open, PNP transistor output |
| Electrical Connection | Cable | PUR cable with flying leads |
| Cable Length | 2.0 m (6.5 ft) | Polyurethane (PUR) cable |
| Rated Operating Current | ā¤ 200 mA | Maximum current rating |
| Ripple Voltage | ā¤ 10% UBmax | Power supply stability requirement |
| Sensor Type | Capacitive | Detects metallic and non-metallic objects |
Key Features and Benefits
Compact Design
5.5mm thin rectangular body allows installation in tight spaces where traditional sensors cannot fit.
Wide Voltage Range
10-30 VDC operating voltage provides compatibility with various industrial power systems.
PNP Output
Positive switching output (PNP) with normally open contact for standard PLC input compatibility.
Durable Construction
Industrial-grade materials and PUR cable ensure reliable operation in harsh environments.
Industrial Applications
The BC10-QF5.5-AP6X2 capacitive proximity sensor is designed for diverse industrial automation applications:
- Packaging Machinery: Detecting presence of packages, containers, and materials on conveyor systems
- Material Handling: Position detection in automated storage and retrieval systems
- Automotive Manufacturing: Component presence verification in assembly lines
- Food Processing: Level detection of liquids and granular materials in tanks and hoppers
- Pharmaceutical Equipment: Precise detection of vials, caps, and packaging materials
- Printing Industry: Paper and media detection in printing and copying equipment
- Wood Processing: Detection of wood panels and materials in cutting machines
PLC Integration: This sensor is compatible with all major PLC brands including Siemens, Allen-Bradley, Mitsubishi, Omron, and Schneider Electric. The PNP output with normally open contact provides standard interface for digital input modules.
Industry Recognition and Trust Metrics
The BC10-QF5.5-AP6X2 is manufactured by Turck, a globally recognized leader in industrial automation with over 50 years of experience. Key trust indicators include:
- ISO 9001 Certified: Manufactured under strict quality management systems
- Global Availability: Distributed through authorized partners worldwide
- Technical Documentation: Comprehensive datasheets available from Turck's official website
- Industry Standards: Complies with relevant IEC and UL standards for industrial sensors
- Customer Reviews: Highly rated by industrial automation professionals on major platforms
External References: Official product information can be found on Turck's product page and detailed technical specifications in the product datasheet PDF.
Frequently Asked Questions
Installation and Wiring Guidelines
For optimal performance of the BC10-QF5.5-AP6X2 capacitive proximity sensor:
- Mounting: Ensure proper alignment with the target object. The sensing face should be parallel to the target surface for maximum detection range.
- Clearance: Maintain adequate clearance from metal objects and other sensors to prevent interference.
- Power Supply: Use a stable DC power supply within the 10-30V range with minimal ripple (ā¤10% of maximum voltage).
- Wiring: Follow standard industrial wiring practices. Use appropriate cable glands for environmental protection if needed.
- Testing: After installation, test the sensor with the actual target material to verify proper detection and adjust if necessary.
- Maintenance: Regularly clean the sensing face to prevent buildup of dust, oil, or other contaminants that could affect performance.
Safety Note: Always disconnect power before installing or servicing electrical components. Follow local electrical codes and safety regulations.
Technical Support and Documentation
For comprehensive technical support and documentation:
- Official Datasheet: Download the complete technical specifications from Turck's official website
- Application Support: Contact authorized Turck distributors for application-specific guidance
- Training Resources: Access online training materials for proper sensor selection and installation
- Warranty Information: Standard manufacturer warranty applies - consult your supplier for details
- Replacement Parts: Genuine replacement cables and accessories available through authorized channels
