DMF6104N PLC Module: Advanced Industrial Automation Solution
On this page
The DMF6104N photo set shows a display assembly with a blue viewing surface, black bezel and green driver PCB. It does not show the PLC module described in the retained title. The 13 March 2026 entry records one new domestic replacement unit; no warranty duration is specified in that entry. All six recorded photographs are retained, and the record contains no video.
Identification and delivery details
A rear sticker reads DMF6104N and FJ20260311. A smaller sticker reads F26-03-12 OK. These are visible identification/inspection markings, not an independent test report or proof of a manufacture date. The rear has several integrated circuits, corner mounting holes and a single connection row labelled CON, 1 and 14. The photographs show soldered pads rather than a supplied mating cable or host connector.
The front is unpowered, with reflective film over the blue display surface. Side views show the thin layered assembly, bezel and PCB, and one edge carries SR2375 with K and A markings. Resolution, controller protocol, operating voltage, backlight supply and dimensions are not established by these photos. The entry's domestic-replacement wording is retained rather than presenting the unit as a factory-original branded display.
| Item | Evidence |
|---|---|
| Photographed assembly | DMF6104N-labelled display and driver PCB |
| Rear identifier | DMF6104N; FJ20260311 sticker |
| Inspection sticker | F26-03-12 OK; no associated test report shown |
| Connection evidence | Rear CON row marked 1 to 14; mating cable not pictured |
| Visible construction | Blue viewing surface, black bezel, green PCB and corner mounting holes |
| Edge markings | SR2375; K and A visible on one edge |
| Verified electrical specifications | Voltage, resolution, interface protocol and backlight requirements not established |
| Delivery terms | One item; new domestic replacement as recorded; 13 March 2026; warranty duration unspecified |
| Record weight | 0.5 kg; no photographed weighing |
Swipe or scroll horizontally to read the full table.
Physical description follows all six photographs. The actual old-body images match the DMF6104N record. Its prior PLC claims are unsupported by the display assembly shown, and no video was listed or invented.
Matching this part
Send the existing display's full label, front/back photographs, connection pinout and host equipment model. Confirm mechanical fit, display interface, supply and backlight requirements for this replacement before purchase.
Request an illuminated display test and compatible host demonstration if needed. The OK sticker and an unpowered blue surface do not establish pixel condition, contrast, backlight life or compatibility with the original unit.
Photos and recorded media
Related records and products
The separate G121I1-L01 display record documents another screen assembly under a PLC title. Matching its connectors or model does not establish interchangeability. Contact KOEED with your original display evidence.
Request this part
Send DMF6104N, host model, pinout, dimensions and quantity. Request replacement compatibility, powered display evidence, available condition and written warranty terms.
