Fuji 7MBR15SA120F-01 Power Supply Module: Complete Guide for Industrial Automation
Fuji 7MBR15SA120F-01 Power Supply Module
High-Performance IGBT Power Module for Industrial Automation Applications
Product Overview
The Fuji 7MBR15SA120F-01 is a premium Power Integrated Module (PIM) designed for industrial automation and motor drive applications. This advanced power supply module combines high efficiency with robust performance, making it an ideal choice for demanding industrial environments where reliability and precision are paramount.
Technical Specifications
| Parameter | Specification | Description |
|---|---|---|
| Model Number | 7MBR15SA120F-01 | Fuji Electric Power Integrated Module |
| Voltage Rating | 1200V | Maximum collector-emitter voltage |
| Current Rating | 15A | Maximum collector current |
| VCE(sat) | 1.9V (typical) | Low collector-emitter saturation voltage |
| Package Type | PIM (Power Integrated Module) | Complete power stage solution |
| Mounting Type | Printed Circuit Board Mount | Designed for PCB installation |
| Integrated Circuits | Converter diode bridge, Dynamic brake circuit | Multiple functions in single package |
| Operating Temperature | -40°C to +125°C | Wide temperature range for industrial use |
Key Features and Benefits
- Low VCE(sat): Reduced power losses and improved efficiency in switching applications
- Compact Package Design: Space-saving solution for modern industrial equipment
- Complete Power Stage Solution: Integrated converter diode bridge and dynamic brake circuit
- High Reliability: Designed for demanding industrial environments with extended lifespan
- Easy Integration: PCB mount design simplifies installation and maintenance
- Thermal Performance: Optimized heat dissipation for stable operation
Applications
The Fuji 7MBR15SA120F-01 power supply module is specifically designed for industrial automation applications, including:
- Motor Drive Inverters: AC motor control and variable frequency drives
- Industrial Power Supplies: High-efficiency power conversion systems
- PLC Systems: Programmable logic controller power stages
- Robotics: Power modules for robotic control systems
- HVAC Systems: Heating, ventilation, and air conditioning controls
- Industrial Machinery: Power control for manufacturing equipment
Frequently Asked Questions
Industry Recognition and Standards
Fuji Electric is a globally recognized leader in power electronics with over 40 years of experience in IGBT technology. The 7MBR15SA120F-01 module complies with international industrial standards and is manufactured using advanced semiconductor technology to ensure reliability and performance.
According to industry sources, Fuji IGBT modules are known for their:
- High reliability in industrial applications
- Excellent thermal performance
- Consistent quality across production batches
- Comprehensive technical support and documentation
Ready to Integrate the Fuji 7MBR15SA120F-01 into Your System?
This high-performance power supply module is available for immediate purchase through our authorized distributor network. For detailed pricing, technical specifications, and application support, visit our official product page.
View Product Details & PricingFor additional information about the Fuji 7MBR15SA120F-01 power supply module, including datasheets, application notes, and technical support, visit our comprehensive product resource center at https://koeed.com/products/new-fuji-7mbr15sa120f-01-power-supply-module.
