Product Overview
The Mitutoyo 2109AB-10 is a high-precision micron dial indicator designed for industrial measurement applications requiring exceptional accuracy. This instrument features a 0.1mm measurement range with 0.001mm resolution, making it ideal for quality control, machine setup, and precision manufacturing processes in PLC-controlled automation environments.
As a direct replacement for the 2109SB-10 model, the 2109AB-10 offers enhanced features and improved reliability for demanding industrial applications. For detailed specifications and purchasing information, visit the official product page on Koeed.com.
Technical Specifications
| Parameter | Specification | Value |
|---|---|---|
| Model Number | 2109AB-10 | Replaces 2109SB-10 |
| Measurement Range | Total Travel | 0.1mm |
| Resolution | Smallest Increment | 0.001mm (1 micron) |
| Accuracy | Maximum Error | Ā±0.003mm |
| Dial Diameter | Face Size | Approximately 40mm |
| Graduation | Scale Division | 0.01mm per division |
| Contact Point | Tip Material | Hardened Steel/Carbide |
| Operating Temperature | Recommended Range | 10Ā°C to 40Ā°C |
| Mounting | Connection Type | Standard 8mm diameter stem |
Key Features and Benefits
- High Precision Measurement: 0.001mm resolution enables detection of minute dimensional variations
- Direct Replacement: Compatible with existing 2109SB-10 installations and fixtures
- Durable Construction: Built to withstand industrial environments with shock-resistant design
- Clear Readability: Large dial face with contrasting markings for easy reading
- Versatile Mounting: Standard 8mm stem compatible with most indicator holders
- Repeatable Accuracy: Consistent performance for reliable quality control measurements
- PLC Integration Ready: Suitable for automated measurement systems in PLC-controlled environments
Industrial Applications
The Mitutoyo 2109AB-10 finds extensive use in various industrial sectors:
Primary Application Areas:
- Machine Tool Setup: Precision alignment of CNC machines and lathes
- Quality Control: Dimensional inspection of manufactured components
- Automated Assembly: Position verification in PLC-controlled assembly lines
- Mold and Die Making: Precision measurement of tooling components
- Research and Development: Laboratory measurements and prototype validation
- Maintenance and Repair: Equipment alignment and wear measurement
Comparison with Previous Models
| Feature | 2109AB-10 | 2109SB-10 | Improvement |
|---|---|---|---|
| Resolution | 0.001mm | 0.001mm | Maintained |
| Durability | Enhanced | Standard | Improved shock resistance |
| Readability | High contrast dial | Standard dial | Better visibility in low light |
| Compatibility | Full backward compatibility | N/A | Direct replacement capability |
| Warranty | Extended coverage | Standard | Longer protection period |
Frequently Asked Questions (FAQ)
Integration with PLC Systems
In modern industrial automation, the Mitutoyo 2109AB-10 plays a crucial role in PLC-controlled measurement systems:
- Automated Quality Gates: Integrated into production lines for 100% inspection
- Statistical Process Control: Data collection for SPC analysis and trend monitoring
- Closed-loop Control: Feedback for automatic machine adjustment based on measurement data
- Batch Traceability: Measurement data logging for quality documentation
Maintenance and Care
To ensure optimal performance and longevity:
- Store in protective case when not in use
- Clean contact points regularly with appropriate solvents
- Avoid excessive force on the measuring spindle
- Protect from extreme temperatures and humidity
- Follow manufacturer's calibration recommendations
Ready to Enhance Your Measurement Capabilities?
The Mitutoyo 2109AB-10 offers the precision and reliability needed for modern industrial applications. Whether you're upgrading existing equipment or implementing new quality control systems, this indicator provides the accuracy and durability required for success.
Get Your Mitutoyo 2109AB-10 TodayContact our technical support team for integration advice and application-specific recommendations.
