Nachi IPH-2B-6.5-11 Internal Gear Pump: Comprehensive Guide for Industrial Automation Applications
Nachi IPH-2B-6.5-11 Internal Gear Pump
High-performance hydraulic gear pump for industrial automation and PLC-controlled systems
Product Overview
The Nachi IPH-2B-6.5-11 is a premium internal gear pump designed for demanding industrial automation applications. This hydraulic gear pump features a displacement of 6.5 cm³/rev and operates at high pressures, making it ideal for PLC-controlled hydraulic systems in manufacturing, material handling, and industrial machinery.
With its cast iron construction and innovative design, the IPH-2B-6.5-11 offers exceptional durability and reliability in continuous operation environments. The pump's compact design and easy maintenance features make it a preferred choice for automation engineers seeking efficient hydraulic power solutions.
Product Images and Video
Product Demonstration Video
This video demonstrates the IPH-2B-6.5-11 internal gear pump in operation, showing installation procedures and operational characteristics.
Key Features and Benefits
High Pressure Performance
Designed for maximum operating pressure up to 21 MPa (210 kgf/cm²), making it suitable for demanding hydraulic applications in industrial automation.
Easy Maintenance Design
Features a new structural design that enables easy maintenance and inspection without requiring complete disassembly of the system.
Excellent Durability
Constructed with high-quality cast iron and aluminum components for extended service life in continuous operation environments.
Compact Size
Space-saving design allows for installation in tight spaces while maintaining high performance characteristics.
PLC Compatibility
Ideal for integration with PLC-controlled hydraulic systems, providing precise flow control and reliable operation.
Wide Speed Range
Operates efficiently across a broad range of revolution speeds, from minimum to maximum operating conditions.
Technical Specifications
| Parameter | Specification | Unit |
|---|---|---|
| Model Number | IPH-2B-6.5-11 | - |
| Displacement | 6.5 | cm³/rev |
| Rated Pressure | 17.5 | MPa |
| Maximum Operating Pressure | 21.0 | MPa (210 kgf/cm²) |
| Minimum Revolution Speed | 600 | min⁻¹ |
| Maximum Revolution Speed | 3600 | min⁻¹ |
| Pump Body Material | Cast Iron | - |
| O-Ring Material | Aluminum | - |
| Design Number | 11 | - |
| Manufacturer | Nachi America Inc. | - |
Applications in Industrial Automation
The Nachi IPH-2B-6.5-11 internal gear pump finds extensive applications in various industrial automation scenarios:
- PLC-Controlled Hydraulic Systems: Integration with Siemens, Allen-Bradley, or Mitsubishi PLCs for precise hydraulic control
- Injection Molding Machines: Providing consistent hydraulic pressure for mold clamping and injection processes
- Material Handling Equipment: Powering hydraulic lifts, conveyors, and robotic arms in automated warehouses
- Machine Tools: Supplying hydraulic power to CNC machines, presses, and cutting equipment
- Packaging Machinery: Driving hydraulic systems in automated packaging and filling lines
- Industrial Robotics: Providing hydraulic power for robotic end-effectors and positioning systems
Comparison with Similar Products
| Feature | IPH-2B-6.5-11 | IPH-2B-5-11 | IPH-2B-8-11 |
|---|---|---|---|
| Displacement | 6.5 cm³/rev | 5.0 cm³/rev | 8.0 cm³/rev |
| Maximum Pressure | 21 MPa | 21 MPa | 21 MPa |
| Speed Range | 600-3600 min⁻¹ | 600-3600 min⁻¹ | 600-3600 min⁻¹ |
| Typical Flow Rate* | 23.4 L/min @ 3600 rpm | 18.0 L/min @ 3600 rpm | 28.8 L/min @ 3600 rpm |
| Application | Medium flow systems | Low flow systems | High flow systems |
*Calculated based on displacement and maximum speed
Frequently Asked Questions (FAQ)
Installation and Integration Guidelines
For optimal performance and longevity, follow these installation guidelines:
- Mounting: Ensure proper alignment between pump and motor shafts. Use flexible couplings to accommodate minor misalignments.
- Piping: Use clean, deburred piping with proper support to prevent stress on pump connections.
- Filtration: Install adequate filtration (typically 10 micron) to protect pump components from contamination.
- Priming: Prime the pump before initial startup to prevent dry running damage.
- PLC Integration: Program PLC for soft start/stop sequences to reduce hydraulic shock and extend component life.
- Monitoring: Implement pressure and temperature monitoring through PLC analog inputs for predictive maintenance.
Trust and Quality Metrics
Manufacturer Reputation: Nachi is a globally recognized manufacturer with over 90 years of experience in precision engineering and hydraulic components.
Quality Standards: The IPH-2B-6.5-11 is manufactured under ISO 9001 quality management systems, ensuring consistent performance and reliability.
Industry Adoption: Widely used in automotive manufacturing, industrial machinery, and material handling equipment worldwide.
Technical Support: Comprehensive technical documentation and support available through authorized distributors and manufacturer representatives.
Warranty: Standard manufacturer warranty with extended options available for industrial applications.
External References and Resources
For additional technical information and support:
- Manufacturer Specifications: Available through Nachi America Inc. official documentation
- Industry Standards: Compliant with ISO 4401 hydraulic component standards
- PLC Integration Guides: Siemens, Allen-Bradley, and Mitsubishi PLC hydraulic control application notes
- Maintenance Manuals: Detailed service and maintenance procedures from authorized distributors
- Technical Support: Available through Motion Industries and other authorized industrial distributors
Conclusion
The Nachi IPH-2B-6.5-11 internal gear pump represents a reliable, high-performance solution for industrial automation hydraulic systems. With its 6.5 cm³/rev displacement, maximum operating pressure of 21 MPa, and durable construction, this pump delivers consistent performance in demanding applications.
For automation engineers and system integrators, the IPH-2B-6.5-11 offers excellent PLC compatibility, easy maintenance features, and proven reliability. Whether powering injection molding machines, material handling equipment, or industrial robotics, this pump provides the hydraulic power needed for efficient, automated operations.
When integrated with proper filtration, monitoring systems, and PLC control, the IPH-2B-6.5-11 contributes to optimized system performance, reduced downtime, and extended service life in industrial automation environments.
