Omron E3F-R1C4 Photoelectric Sensor: Comprehensive Guide for Industrial Automation
Omron E3F-R1C4 Photoelectric Sensor
Advanced Detection Technology for Industrial Automation Systems
Product Overview
The Omron E3F-R1C4 is a high-performance photoelectric sensor designed for reliable object detection in industrial automation environments. This compact and versatile sensor offers precise detection capabilities, making it an essential component in PLC-based control systems, packaging machinery, material handling equipment, and various manufacturing applications.
For detailed specifications and purchasing information, visit the official product page: Omron E3F-R1C4 Photoelectric Sensor.
Product Images and Visual Documentation
Technical Specifications
| Parameter | Specification | Details |
|---|---|---|
| Model | E3F-R1C4 | Omron Photoelectric Sensor |
| Detection Method | Reflective | Through-beam or retro-reflective operation |
| Detection Distance | 1 meter | Standard detection range |
| Light Source | Infrared LED | 850nm wavelength for reliable detection |
| Output Configuration | NPN or PNP | Selectable output type based on application |
| Response Time | 1ms maximum | Fast response for high-speed applications |
| Power Supply | 12-24V DC | Standard industrial voltage range |
| Protection Rating | IP67 | Dust-tight and waterproof protection |
| Operating Temperature | -25°C to +55°C | Suitable for harsh industrial environments |
| Connection Type | 2m cable or connector | Flexible installation options |
Key Features and Benefits
High Precision Detection
The E3F-R1C4 offers exceptional detection accuracy with its advanced photoelectric technology. The sensor can reliably detect objects as small as 10mm at its maximum detection distance, making it ideal for precision manufacturing applications.
Robust Industrial Design
With an IP67 protection rating, this sensor is designed to withstand harsh industrial environments including dust, moisture, and vibration. The rugged construction ensures long-term reliability in demanding applications.
Easy Installation and Configuration
The sensor features simple mounting options and intuitive configuration. The built-in indicator LEDs provide clear status information for easy setup and troubleshooting.
Versatile Applications
From packaging machinery to automated assembly lines, the E3F-R1C4 integrates seamlessly with PLC systems including Siemens, Allen-Bradley, Mitsubishi, and Omron controllers.
Industrial Applications
- Packaging Machinery: Product presence detection, counting, and positioning
- Material Handling: Conveyor belt monitoring and object detection
- Automotive Manufacturing: Part verification and assembly line control
- Food and Beverage: Bottle/can detection and filling level control
- Pharmaceutical: Package verification and quality control
- Electronics Assembly: Component presence detection and positioning
For specific application guidance and technical support, visit our detailed product page.
Trust and Quality Metrics
Frequently Asked Questions
Installation and Wiring Guidelines
Proper installation is crucial for optimal sensor performance. Follow these guidelines:
- Mount the sensor securely using the provided mounting brackets
- Ensure proper alignment between transmitter and receiver (for through-beam models)
- Connect power supply (12-24V DC) to the appropriate terminals
- Connect output signal to your PLC input module
- Adjust sensitivity using the built-in potentiometer
- Test detection with target objects at various distances
For complete wiring diagrams and installation instructions, refer to the documentation available at our product page.
Technical Support and Resources
Our technical support team provides comprehensive assistance for the E3F-R1C4 photoelectric sensor. Available resources include:
- Detailed datasheets and technical specifications
- Application notes for various industries
- Wiring diagrams and installation guides
- Troubleshooting manuals
- PLC integration examples
Visit https://koeed.com/products/new-omron-e3f-r1c4-photoelectric-sensor for complete product information, pricing, and technical documentation.
View Product Details & PricingIndustry Standards and Certifications
The Omron E3F-R1C4 photoelectric sensor complies with international standards including:
- CE Marking (European Conformity)
- UL Recognition (Underwriters Laboratories)
- RoHS Compliance (Restriction of Hazardous Substances)
- ISO 9001 Quality Management System
- Industrial Safety Standards
