Omron E3JK-5M2-N Photoelectric Switch
5-Meter Sensing Distance Industrial Photoelectric Sensor with Relay Output
The Omron E3JK-5M2-N is a high-performance photoelectric switch designed for industrial automation applications requiring reliable object detection at distances up to 5 meters. This versatile sensor combines advanced infrared LED technology with robust construction for demanding industrial environments.
View Product Details & Purchase
Technical Specifications
| Parameter | Specification | Details |
|---|---|---|
| Sensing Distance | 5 meters | Maximum detection range |
| Light Source | Infrared LED | High-intensity infrared light source |
| Output Configuration | Relay SPDT-DO | Single Pole Double Throw - Dry Output |
| Connection Method | Pre-Cable | Factory-installed cable connection |
| Power Supply | 24-240 VAC / 12-240 VDC | Wide voltage range compatibility |
| Operation Mode | DARK-ON | Output activates when light is blocked |
| Detection Method | Transmitter-Receiver | Through-beam sensing technology |
| IP Rating | IP65 | Dust-tight and protected against water jets |
| Max Operating Current | 3A | High current handling capability |
| Response Time | ≤ 20ms | Fast response for high-speed applications |
Key Features & Benefits
Advanced Sensing Technology
The E3JK-5M2-N utilizes infrared LED technology with a 5-meter sensing distance, making it ideal for applications requiring long-range object detection. The through-beam design ensures reliable operation even in challenging environmental conditions.
Versatile Power Compatibility
With support for both AC (24-240V) and DC (12-240V) power supplies, this photoelectric switch offers exceptional flexibility for integration into various industrial control systems. This wide voltage range compatibility reduces the need for additional power conversion equipment.
Robust Industrial Design
Featuring an IP65 protection rating, the E3JK-5M2-N is designed to withstand harsh industrial environments. The enclosure provides protection against dust ingress and water jets, ensuring reliable operation in manufacturing facilities, warehouses, and outdoor applications.
Relay Output Configuration
The SPDT (Single Pole Double Throw) relay output provides dry contact switching capability, allowing direct interface with PLCs, contactors, and other control devices without requiring additional interface modules.
For detailed specifications and to purchase this industrial-grade photoelectric switch, visit our product page.
Industrial Applications
The Omron E3JK-5M2-N photoelectric switch is suitable for a wide range of industrial automation applications:
- Conveyor Systems: Object detection, package counting, and position verification
- Material Handling: Presence detection for automated storage and retrieval systems
- Packaging Machinery: Product positioning and fill level detection
- Automotive Manufacturing: Part presence verification on assembly lines
- Warehouse Automation: Pallet detection and inventory management
- Security Systems: Intrusion detection and access control
- Food Processing: Container detection and production line monitoring
- Pharmaceutical Manufacturing: Sterile environment object detection
The E3JK-5M2-N is particularly valuable in applications requiring long-distance sensing capabilities combined with industrial-grade reliability.
Installation & Wiring Guidelines
Mounting Considerations
When installing the E3JK-5M2-N photoelectric switch, ensure proper alignment between the transmitter and receiver units. The maximum sensing distance of 5 meters can be achieved with optimal alignment and clean optical surfaces.
Wiring Configuration
The pre-cable connection simplifies installation with clearly labeled wires:
- Brown Wire: Power supply positive/phase
- Blue Wire: Power supply negative/neutral
- Black Wire: Normally open (NO) contact
- White Wire: Common contact
- Gray Wire: Normally closed (NC) contact
Environmental Considerations
While the IP65 rating provides excellent protection, avoid direct exposure to corrosive chemicals or extreme temperatures beyond the specified operating range (-25°C to +55°C).
For complete installation instructions and technical support, refer to the product documentation available on our website.
