Phoenix Contact 1095802 SAC-8P-2,0-680/M12FS FDN Sensor/Actuator Cable: Complete Technical Guide
Phoenix Contact 1095802 SAC-8P-2,0-680/M12FS FDN Sensor/Actuator Cable
Product Code: 1095802 | Manufacturer: Phoenix Contact
Product Overview
The Phoenix Contact 1095802 SAC-8P-2,0-680/M12FS FDN is a premium-grade sensor/actuator cable designed for industrial automation applications. This 8-position cable features M12 connectors with A-coding, providing reliable connectivity for sensors, actuators, and other industrial devices in harsh environments.
Technical Specifications
| Parameter | Specification |
|---|---|
| Product Category | Sensor Cables / Actuator Cables |
| Manufacturer Part Number | 1095802 |
| Manufacturer | Phoenix Contact |
| Connector End A | M12 Socket straight |
| Connector End A Pin Count | 8 Position |
| Coding | A-coding |
| Cable Length | 2 meters (2.0 m) |
| Cable Type | SAC-8P-2,0-680/M12FS FDN |
| Shielding | Foil shielding plus drain wire |
| Jacket Material | PVC (Polyvinyl Chloride) |
| Color | Gray |
| Connector End B | Free cable end |
| RoHS Compliance | Yes |
| IP Rating | IP67 (typical for M12 connectors) |
| Operating Temperature | -25Ā°C to +80Ā°C (typical for PVC cables) |
Key Features
- 8-Position Configuration: Supports multiple signal transmission requirements
- M12 A-Coding: Standard industrial connector for sensors and actuators
- Enhanced Shielding: Foil plus drain wire for superior EMI/RFI protection
- PVC Jacket: Durable, flexible, and resistant to oils and chemicals
- 2-Meter Length: Optimal for most industrial installation scenarios
Industrial Applications
- Factory automation systems
- PLC and DCS installations
- Sensor networks in manufacturing
- Actuator control systems
- Industrial robotics
- Material handling equipment
- Packaging machinery
Quality Standards
- RoHS compliant for environmental safety
- Industrial-grade durability
- Tested for vibration resistance
- UV resistant (typical for industrial cables)
- Flame retardant properties
Installation and Usage Guidelines
The Phoenix Contact 1095802 cable is designed for easy installation in industrial environments. The M12 connector features a screw-locking mechanism that ensures secure connections even in high-vibration applications. The free cable end allows for flexible termination options, including direct wiring to terminal blocks or connection to other industrial interfaces.
Recommended Installation Practices:
- Ensure proper strain relief at cable entry points
- Maintain minimum bend radius of 8x cable diameter
- Use appropriate cable glands for IP67 protection
- Follow local electrical codes and regulations
- Test connections before final installation
Frequently Asked Questions (FAQ)
A-coding is the standard coding for sensor/actuator connections in industrial automation. It ensures proper mating with compatible devices and prevents incorrect connections that could damage equipment.
While the cable has PVC insulation that provides some weather resistance, for permanent outdoor installations, additional protection such as conduit or UV-resistant sleeving is recommended to ensure long-term reliability.
Standard M12 sensor/actuator cables typically have a voltage rating of 30V AC/DC for signal applications and 250V AC/DC for power applications. Always consult the manufacturer's datasheet for specific ratings.
While this cable uses M12 connectors, PROFINET and Ethernet/IP typically require D-coding for data transmission. This A-coded cable is designed for sensor/actuator applications rather than industrial Ethernet networks.
In industrial environments, visual inspections should be conducted quarterly, with comprehensive testing annually. Check for physical damage, connector integrity, and proper strain relief.
Industry Standards and Compliance
The Phoenix Contact 1095802 cable complies with multiple international standards:
- IEC 61076-2-101: Connectors for electronic equipment
- ISO/IEC 11801: Generic cabling for customer premises
- UL/CSA Standards: For North American markets
- CE Marking: European conformity
- RoHS Directive 2011/65/EU: Restriction of hazardous substances
External References and Technical Resources
For additional technical information and support:
- Manufacturer Website: Phoenix Contact Product Page
- Distributor Information: Mouser Electronics Product Page
- Technical Documentation: Available on Phoenix Contact's official website
- Industry Applications: Factory automation, process control, robotics
Conclusion
The Phoenix Contact 1095802 SAC-8P-2,0-680/M12FS FDN sensor/actuator cable represents a reliable solution for industrial automation connectivity needs. With its 8-position configuration, M12 A-coding, and robust construction, it provides dependable performance in demanding industrial environments. The combination of quality materials, proper shielding, and industry-standard compliance makes this cable an excellent choice for connecting sensors, actuators, and other industrial devices in PLC-based automation systems.
For system integrators and maintenance professionals, this cable offers the reliability and durability needed to minimize downtime and ensure continuous operation in industrial settings. Always consult the manufacturer's latest documentation for the most current specifications and installation guidelines.
