Turck BI10-M30-AZ3X/S90 4316403 Inductive Proximity Sensor: Complete Technical Guide
Turck BI10-M30-AZ3X/S90 4316403 Inductive Proximity Sensor
Product Identification: 4316403
Product Overview
The Turck BI10-M30-AZ3X/S90 4316403 is a high-performance inductive proximity sensor designed for industrial automation applications. This M30 threaded sensor offers reliable metal detection with a 10mm switching distance, making it ideal for various manufacturing and process control environments.
Technical Specifications
| Parameter | Specification | Details |
|---|---|---|
| Product Type | Inductive Proximity Sensor | BI10-M30-AZ3X/S90 |
| Identification Number | 4316403 | Turck Product Code |
| Rated Switching Distance | 10 mm | Standard detection range |
| Mounting Conditions | Flush | Can be mounted flush with metal surfaces |
| Operating Voltage | 20…250 VAC / 10…300 VDC | Wide voltage range for flexibility |
| Output Function | NO contact, 2-wire | Normally Open, 2-wire configuration |
| Thread Type | M30 × 1.5 | Standard industrial thread size |
| Material | Chrome-plated brass | Durable and corrosion-resistant |
| Smallest Operating Current | ≥ 3 mA | Low power consumption |
| Switching Frequency | 0.02 kHz | 20 Hz operating frequency |
| Cable Length | 5 meters (standard variant) | Adequate for most installations |
Key Features and Benefits
- Wide Voltage Range: Operates on both AC (20-250V) and DC (10-300V) power supplies
- 2-Wire Configuration: Simplified wiring with NO (Normally Open) contact
- M30 Threaded Design: Standard industrial mounting compatibility
- Chrome-plated Brass Construction: Excellent durability and corrosion resistance
- Flush Mounting Capability: Can be installed flush with metal surfaces
- 10mm Switching Distance: Reliable detection range for various applications
- Low Power Consumption: Minimum operating current of 3 mA
- Industrial Grade: Designed for harsh industrial environments
Industrial Applications
Primary Application Areas:
- Material Handling Systems: Position detection in conveyors and transfer systems
- Machine Tooling: Tool presence detection and positioning
- Packaging Machinery: Product detection and counting applications
- Automotive Manufacturing: Part presence verification in assembly lines
- Robotics: End effector position sensing
- Process Control: Valve position monitoring and control
- Safety Systems: Machine guarding and access control
Installation and Wiring Guidelines
Mounting Instructions:
The BI10-M30-AZ3X/S90 features a standard M30 × 1.5 threaded design for easy installation. For flush mounting applications, ensure proper clearance around the sensor to avoid interference with the sensing field.
Wiring Configuration:
This 2-wire sensor requires simple connection to power and load. The NO (Normally Open) configuration means the switch closes when a metal target is detected within the 10mm sensing range.
Environmental Considerations:
Designed for industrial environments with temperature ranges typically from -25°C to +70°C. The chrome-plated brass construction provides excellent resistance to oils, coolants, and mild chemicals.
Frequently Asked Questions (FAQ)
Comparison with Similar Products
| Feature | BI10-M30-AZ3X/S90 | Standard M30 Sensors | Premium Features |
|---|---|---|---|
| Voltage Range | 20-250V AC / 10-300V DC | Typically 10-30V DC only | Wide range compatibility |
| Construction | Chrome-plated brass | Stainless steel or plastic | Superior corrosion resistance |
| Mounting | Flush capable | May require non-flush | Installation flexibility |
| Switching Distance | 10mm | 5-8mm typical | Extended detection range |
| Output Type | 2-wire NO | Various configurations | Simplified wiring |
Maintenance and Troubleshooting
Regular Maintenance:
Periodically clean the sensor face to remove dust, oil, or metal particles that may affect performance. Check mounting integrity and cable condition during routine maintenance schedules.
Common Issues and Solutions:
- No Detection: Verify power supply, check wiring connections, ensure target is within 10mm range
- Intermittent Operation: Check for loose connections, verify stable power supply, inspect for environmental interference
- False Triggers: Ensure proper mounting clearance, check for nearby metal objects, verify correct sensor type for application
Technical References: Information based on Turck product documentation and industrial automation standards. Product specifications may vary by region and specific product variant.
External Sources: Turck product datasheets and technical documentation available at turck.us and turck.de
