Vickers H-507848 Solenoid Valve Coil: Complete Technical Guide and Applications
Vickers H-507848 Solenoid Valve Coil: Complete Technical Guide and Applications
Professional-grade solenoid coil for industrial hydraulic systems
Product Overview
The Vickers H-507848 solenoid valve coil is a high-performance industrial component designed for reliable operation in demanding hydraulic applications. This 24V DC solenoid coil is engineered to provide superior environmental protection and consistent performance in both mobile and industrial settings. As a critical component in hydraulic control systems, the H-507848 ensures precise valve actuation and system reliability.
For detailed specifications and purchasing information, visit the official product page: Vickers H-507848 Solenoid Valve Coil.
Product Images
Technical Specifications
| Parameter | Specification | Details |
|---|---|---|
| Part Number | H-507848 / H507848 | Also known as: 103690 |
| Voltage Rating | 24V DC | Direct current operation |
| Power Rating | 30W | Power consumption |
| Weight | 370-400 grams | Approximate weight range |
| Coil Type | Encapsulated | Cetop 3 standard |
| Protection Rating | IP65-IP69K | High environmental protection |
| Connection Type | Integrated wire leads | Direct wiring capability |
| Core Diameter | 23mm ID | Internal diameter measurement |
| Manufacturer | Eaton Vickers | Original equipment manufacturer |
Key Features and Benefits
Superior Environmental Protection
The H-507848 features IP65 to IP69K protection ratings, making it suitable for harsh industrial environments. The encapsulated design provides excellent resistance to moisture, dust, chemicals, and high-pressure washdown conditions.
One-Piece Shell Design
The exclusive one-piece shell construction offers space-saving benefits while providing maximum protection. This design is retrofittable to existing systems, allowing for easy upgrades without major modifications.
Industrial-Grade Performance
Engineered for demanding applications, this solenoid coil delivers consistent performance with minimal maintenance requirements. The 24V DC operation ensures compatibility with standard industrial control systems.
Reliable Valve Actuation
With precise electromagnetic characteristics, the H-507848 ensures accurate and repeatable valve actuation, critical for maintaining system pressure and flow control in hydraulic applications.
Applications and Industries
The Vickers H-507848 solenoid valve coil finds extensive use across multiple industries due to its robust design and reliable performance. Discover this versatile component at Koeed's official product page.
Excavators, bulldozers, cranes
Tractors, harvesters, irrigation systems
Hydraulic presses, injection molding machines
Forklifts, aerial work platforms
Mobile equipment and vehicles
Compatibility and Replacement
The H-507848 solenoid coil is designed as a direct replacement for original Vickers components. It maintains compatibility with existing valve bodies and mounting configurations, ensuring seamless integration into current systems.
Compatible Part Numbers:
- H-507848 (Primary designation)
- H507848 (Alternate format)
- 103690 (Manufacturer reference)
- K03/13 (Series designation)
For guaranteed compatibility and performance, always source genuine components from authorized distributors like Koeed's official store.
Quality Assurance and Trust Metrics
Manufacturer Certification: Original Eaton Vickers design specifications
Environmental Standards: IP65-IP69K certified protection ratings
Industry Compliance: Meets Cetop 3 standards for hydraulic components
Performance Testing: Factory-tested for electrical and mechanical reliability
Warranty Support: Available through authorized distributors
Frequently Asked Questions (FAQ)
The Vickers H-507848 operates at 24V DC with a power rating of 30W. This standard industrial voltage ensures compatibility with most control systems.
The H-507848 features IP65 to IP69K protection ratings, providing excellent resistance to dust, water jets, and high-pressure washdown conditions.
This coil is commonly used in construction equipment (excavators, bulldozers), agricultural machinery, industrial hydraulic systems, material handling equipment, and mobile hydraulic applications.
Yes, the H-507848 is designed as a direct replacement for original Vickers components and maintains full compatibility with existing valve bodies and mounting configurations.
Genuine Vickers H-507848 solenoid coils are available through authorized distributors. You can find authentic components at Koeed's official product page.
The coil weighs approximately 370-400 grams and features a 23mm internal diameter, conforming to Cetop 3 standards for hydraulic solenoid coils.
Installation and Maintenance
Installation Guidelines:
- Ensure power is disconnected before installation
- Verify proper voltage compatibility (24V DC)
- Check coil resistance and continuity before installation
- Secure connections with appropriate torque specifications
- Verify proper valve actuation after installation
Maintenance Recommendations:
- Regular visual inspection for physical damage
- Check electrical connections for corrosion or looseness
- Monitor coil temperature during operation
- Verify proper valve response during system checks
- Replace if signs of overheating or performance degradation occur
Technical Support and Resources
For technical specifications, installation guidance, and troubleshooting assistance, refer to the original manufacturer documentation or contact authorized technical support channels.
Additional Resources:
- Eaton Vickers technical documentation
- Cetop 3 standards for hydraulic components
- Industrial hydraulic system design guidelines
- PLC and automation integration references
Conclusion
The Vickers H-507848 solenoid valve coil represents industrial-grade reliability and performance in hydraulic control applications. With its robust construction, superior environmental protection, and precise actuation characteristics, this component is essential for maintaining system integrity in demanding industrial environments. Whether for construction equipment, agricultural machinery, or industrial hydraulic systems, the H-507848 delivers consistent performance backed by Eaton Vickers' engineering excellence.
For procurement, technical specifications, and compatibility verification, visit the official product page at https://koeed.com/products/new-one-for-vickers-solenoid-valve-coil-h-507848-h507848.
