Panasonic CX-442-P Photoelectric Sensor: Advanced Background/Foreground Suppression Technology
Panasonic CX-442-P Photoelectric Sensor
Advanced programmable background/foreground suppression technology for precise object detection in industrial automation applications.
Product Overview
The Panasonic CX-442-P is a sophisticated photoelectric sensor from the renowned CX-400 series, featuring programmable background and foreground suppression sensing modes. This versatile sensor offers exceptional performance in challenging industrial environments where precise object detection is critical.
Available for purchase at Koeed.com, this sensor represents Panasonic's commitment to quality and reliability in industrial automation components.
Product Demonstration Video
Watch the CX-442-P in action - demonstrating its programmable sensing capabilities and installation features.
Key Features & Capabilities
- Programmable Sensing Modes: Switch between background suppression (BGS) and foreground suppression (FGS) modes based on application requirements
- Red LED Light Source: Provides reliable detection with consistent performance across various materials and colors
- Adjustable Detection Range: 20-300mm range with 5% hysteresis for stable operation
- NPN Open Collector Output: Compatible with most industrial control systems
- IP67 Protection Rating: Dust-tight and waterproof for harsh industrial environments
- Wide Operating Temperature: -25°C to +55°C for reliable performance in extreme conditions
For detailed specifications and to purchase this sensor, visit Koeed.com where you can find this product new in box with full manufacturer warranty.
Technical Specifications
| Parameter | Specification |
|---|---|
| Model Number | CX-442-P |
| Series | CX-400 |
| Detection Method | Reflective, Diffuse |
| Light Source | Red LED |
| Detection Range | 20-300mm |
| Minimum Detectable Object | 2mm (0.079 inches) |
| Supply Voltage | 12-24 VDC |
| Output Type | NPN Open Collector (PNP selectable) |
| Maximum Operating Current | 0.1A |
| IP Rating | IP67 |
| Operating Temperature | -25°C to +55°C |
| Body Material | PBT (Polybutylene Terephthalate) |
| Connection Type | Cable connection |
| Hysteresis | 5% |
Applications & Industries
The Panasonic CX-442-P photoelectric sensor finds applications across multiple industries due to its versatile programmable sensing capabilities:
Manufacturing & Assembly
- Part presence detection on conveyor systems
- Position verification in assembly lines
- Object counting and sorting applications
Packaging & Material Handling
- Package detection on high-speed lines
- Level detection in bins and hoppers
- Position sensing for robotic pick-and-place systems
Automotive Industry
- Component verification in assembly processes
- Quality control inspection stations
- Safety interlock systems
You can purchase this versatile sensor from Koeed.com for your industrial automation projects.
Frequently Asked Questions (FAQ)
Background Suppression (BGS) mode ignores objects beyond the set detection distance, while Foreground Suppression (FGS) mode ignores objects closer than the set distance. The CX-442-P allows programming of either mode based on application requirements.
The CX-442-P can detect objects as small as 2mm (0.079 inches) away from the sensor face, making it suitable for precise detection applications.
With its IP67 rating, the CX-442-P is dust-tight and waterproof, making it suitable for harsh industrial environments, though direct exposure to extreme weather conditions should be avoided.
The sensor operates on 12-24 VDC power supply with a maximum operating current of 0.1A, making it compatible with standard industrial power systems.
You can purchase the Panasonic CX-442-P photoelectric sensor new in box from Koeed.com, which offers authentic Panasonic products with manufacturer warranty.
Quality Assurance & Trust Metrics
- Manufacturer Authenticity: Genuine Panasonic Industrial Automation product
- IP67 Certification: Independently tested for dust and water resistance
- Industrial Standards Compliance: Meets international industrial automation standards
- Temperature Range Validation: Tested across full operating temperature range
- Warranty Coverage: Full manufacturer warranty when purchased from authorized distributors
For guaranteed authenticity and warranty support, purchase from Koeed.com.
Installation & Configuration
The CX-442-P features a simple cable connection system and can be easily mounted using standard industrial mounting brackets. The programmable sensing modes allow for quick adaptation to different application requirements without hardware changes.
For optimal performance:
- Ensure proper alignment between sensor and target
- Set appropriate detection distance based on application
- Select BGS or FGS mode according to sensing requirements
- Verify operation across expected temperature range
- Regular maintenance and cleaning of sensor lens
Ready to integrate this advanced sensor into your automation system? Visit Koeed.com to purchase your Panasonic CX-442-P photoelectric sensor today.
