Sanyo Denki 9WF1224H1D03 Industrial Cooling Fan - Comprehensive Technical Guide
On this page
What is the Sanyo Denki 9WF1224H1D03 fan?
The 9WF1224H1D03 is a Sanyo Denki SanAce120W cooling fan — a 120 mm square, thin-profile (9WF class) DC fan running from 24 V DC at 0.32 A, and this particular type is the one supplied into FANUC systems under part code A90L-0001-0509, which is printed on the hub label beside the Sanyo type number. The label also carries CE, RU and the S-mark, plus EP 021004P, with SANYO DENKI and Made In The Philippines. Each fan ships sealed in its anti-static bag with the red/white lead and its three-pin connector; this record covers a set of ten, all new and sealed, passed through the Koeed warehouse on 10 November 2025 (about 1 kg per the record), and the photos below show them as received.
Part details
| Field | Value |
|---|---|
| Manufacturer | Sanyo Denki — SanAce120W series, made in the Philippines |
| Model | 9WF1224H1D03 |
| FANUC code | A90L-0001-0509 (printed on the label) — the cooling fan for FANUC CNC/system cabinets |
| Rating | DC 24 V, 0.32 A |
| Lead | Red/white pair ending in a three-pin connector |
| Marks | CE, RU, S-mark; EP 021004P |
| Quantity | 10 fans, factory-sealed |
| Condition | New, unopened (per intake record) |
| Weight | About 1 kg per record (the set) |
| Intake recorded | 10 November 2025 |
Fitting notes
This is the refresh fan for FANUC-controlled machines: when a CNC cabinet or operator panel starts running hot or the system posts a fan alarm, the 9WF1224H1D03 is the drop-in. The thin 9WF body slides where the older thick fans sat, the three-pin connector plugs straight into the FANUC fan board, and the A90L-0001-0509 code on the label is the number to match against the machine's parts list. Sealed bags mean no bench test is strictly needed before fitting, though a spin check costs nothing. Ten fans here are one sealed shipment — stock a panel's spares or replace the whole set at once so all the fans age together.
Photos
All images below are original warehouse photos of the exact fans covered by this record, taken before dispatch. Click any photo to view it full size.
For a higher-current 24 V fan from the same shelf, see the NMB-MAT 5920FT-D5W-B60 set — 4.80 A round-frame cabinet fans.
Sourcing help
KOEED supplies Sanyo Denki fans and FANUC A90L-coded spares, in active and EOL stock. Send the part number for a quote.
Need a quote for this part?
Send us the part number or article link — we will confirm price, availability and lead time.
