Advantech FSP500-60PFG Industrial Power Supply Module: Complete Technical Guide for PLC Systems
Advantech FSP500-60PFG Industrial Power Supply Module
Professional 500W Switching Power Supply for Industrial Automation and PLC Systems
Product Overview
The Advantech FSP500-60PFG is a high-performance industrial-grade switching power supply module designed specifically for demanding automation environments. With a maximum output power of 500W, this power supply provides reliable and stable power delivery for PLC systems, industrial computers, and automation equipment. The Advantech FSP500-60PFG represents the gold standard in industrial power management solutions.
This power supply module features robust construction and advanced protection mechanisms, making it ideal for continuous operation in harsh industrial environments. Whether you're powering complex PLC systems or industrial control panels, the FSP500-60PFG delivers consistent performance and reliability.
Product Images and Visual Documentation
Front View
Side View
Top View
Connector Details
Label Information
Mounting Points
Technical Specifications
Product Demonstration Video
Video demonstration of the Advantech FSP500-60PFG power supply module in operation
Technical Specifications
| Parameter | Specification | Details |
|---|---|---|
| Model Number | FSP500-60PFG | Advantech Industrial Power Supply |
| Maximum Output Power | 500W | Continuous operation capability |
| Input Voltage Range | 90-264V AC | Universal input voltage |
| Input Frequency | 47-63Hz | Wide frequency range |
| Output Voltages | +3.3V, +5V, +12V | Multiple voltage outputs |
| +3.3V & +5V Combined Output | ≤150W | Maximum combined power limit |
| Efficiency | ≥80% | High efficiency operation |
| Operating Temperature | 0°C to 50°C | Industrial temperature range |
| Storage Temperature | -20°C to 70°C | Extended storage capability |
| Safety Certifications | UL, CE, CB | International safety standards |
Key Features and Benefits
Industrial-Grade Reliability
The FSP500-60PFG is built to withstand the rigors of industrial environments. With robust components and advanced thermal management, this power supply ensures continuous operation even in challenging conditions.
Advanced Protection Features
Comprehensive protection mechanisms including over-voltage protection (OVP), over-current protection (OCP), short-circuit protection (SCP), and over-temperature protection (OTP) safeguard both the power supply and connected equipment.
Universal Input Voltage
With an input voltage range of 90-264V AC, the power supply can operate worldwide without requiring voltage adjustments, making it ideal for international deployments.
High Efficiency Operation
Featuring ≥80% efficiency, the Advantech FSP500-60PFG minimizes energy waste and reduces heat generation, contributing to lower operating costs and extended component lifespan.
Multiple Output Voltages
The power supply provides +3.3V, +5V, and +12V outputs, making it compatible with a wide range of industrial equipment and PLC systems.
Applications in Industrial Automation
The FSP500-60PFG is specifically designed for industrial automation applications:
- PLC Systems: Powering Programmable Logic Controllers and I/O modules
- Industrial Computers: Reliable power for industrial PCs and HMI systems
- Control Panels: Central power supply for control cabinets and automation panels
- Machinery Control: Powering motor drives, sensors, and control systems
- Manufacturing Equipment: Reliable power for production line equipment
- Process Control Systems: Critical power for monitoring and control applications
Comparison with Alternative Power Supplies
| Feature | FSP500-60PFG | Standard Power Supply | Competitor Industrial PSU |
|---|---|---|---|
| Maximum Power | 500W | 300-400W | 450-500W |
| Input Voltage Range | 90-264V AC | 100-240V AC | 90-264V AC |
| Industrial Certification | UL, CE, CB | Basic CE | UL, CE |
| Operating Temperature | 0°C to 50°C | 10°C to 40°C | 0°C to 50°C |
| Protection Features | OVP, OCP, SCP, OTP | Basic OVP | OVP, OCP |
| Efficiency | ≥80% | 70-75% | 75-80% |
Frequently Asked Questions (FAQ)
Trust Metrics and Industry Recognition
External References and Technical Documentation
The Advantech FSP500-60PFG is documented across multiple industrial platforms:
- Manufacturer Specifications: FSP TECHNOLOGY INC. provides detailed datasheets for the FSP500-60PFG series
- Industrial Distributors: Available through authorized industrial automation distributors worldwide
- Technical Resources: Complete documentation available at koeed.com/products/new-advantech-fsp500-60pfg-power-supply-module
- Industry Applications: Widely used in PLC systems, industrial computers, and automation control panels
Purchase and Technical Support
The Advantech FSP500-60PFG is available for purchase through authorized distributors. Each unit comes with professional technical support and warranty coverage. For detailed specifications, pricing, and availability, visit the official product page.
View Product Details & PurchaseFor technical inquiries or application-specific questions, consult with our industrial automation specialists who can provide guidance on integration and implementation.
