Panasonic LT4H Digital Timer ATL5117: Comprehensive Guide for Industrial Automation Applications
Panasonic LT4H Digital Timer
Professional-grade DIN rail timer for industrial automation applications
Product Overview
The Panasonic LT4H Digital Timer ATL5117 is a high-performance industrial timer designed for DIN rail mounting applications. This versatile timing device offers exceptional precision and reliability for various automation and control systems. With its wide time range capabilities and user-friendly interface, the ATL5117 has become a preferred choice for engineers and technicians in industrial settings.
Available for fast delivery in stock, this timer provides immediate availability for your automation projects.
Key Features & Benefits
- Wide Time Range: Operation time range from 0.01 seconds to 9999 hours
- Bright Display: 2-color backlight LCD display for excellent visibility in any lighting condition
- Easy Programming: Intuitive interface with simple setting procedures
- DIN Rail Mounting: Standard DIN 48 rail compatibility for easy installation
- High Reliability: Industrial-grade construction for demanding environments
- Multiple Operating Modes: Versatile timing functions for various applications
- Compact Design: Space-saving form factor for efficient panel layout
Technical Specifications
| Parameter | Specification |
|---|---|
| Model Number | ATL5117 |
| Product Series | LT4H Digital Timer |
| Supply Voltage | AC240V |
| Time Range | 0.01 sec to 9999 hours |
| Mounting Type | DIN 48 Rail |
| Display Type | 2-color backlight LCD |
| Contact Configuration | 2 changeover contacts (DPDT) |
| Operating Temperature | -10°C to +55°C |
| Storage Temperature | -25°C to +65°C |
| Dimensions | 48mm x 48mm x 78mm (W x H x D) |
| Weight | Approximately 120g |
Applications in Industrial Automation
The Panasonic LT4H ATL5117 digital timer finds extensive applications across various industrial sectors:
Manufacturing & Production
- Machine cycle timing
- Process sequencing
- Batch processing control
- Conveyor system timing
Building Automation
- Lighting control systems
- HVAC timing operations
- Security system delays
- Energy management
Process Industries
- Chemical processing timing
- Water treatment cycles
- Food processing operations
- Pharmaceutical manufacturing
For immediate project requirements, the ATL5117 is available with fast delivery from our stock.
Frequently Asked Questions
Installation & Wiring Guidelines
Proper installation is crucial for optimal performance and safety:
Mounting Instructions
- Ensure the DIN rail is properly secured in the control panel
- Hook the top of the timer onto the DIN rail
- Push the bottom of the timer until it clicks into place
- Verify the timer is securely mounted
Wiring Precautions
- Always disconnect power before wiring
- Use appropriate wire gauges for the load requirements
- Follow local electrical codes and regulations
- Ensure proper grounding for safety
- Use cable glands or strain relief for wiring entries
For detailed wiring diagrams and specific installation requirements, consult the product documentation available with your ATL5117 purchase.
Comparison with Other Timer Models
| Feature | ATL5117 (LT4H) | Standard Analog Timers | Basic Digital Timers |
|---|---|---|---|
| Time Range | 0.01 sec - 9999 hrs | Limited range | Limited precision |
| Display | 2-color backlight LCD | Analog dial | Basic LED/LCD |
| Accuracy | High precision | Moderate | Variable |
| Programming | Digital interface | Manual dial | Basic buttons |
| Reliability | Industrial grade | Standard | Consumer grade |
| Applications | Industrial automation | Basic timing | Simple controls |
Ready to Upgrade Your Automation System?
The Panasonic LT4H Digital Timer ATL5117 offers the perfect combination of precision, reliability, and ease of use for your industrial timing applications.
Get your ATL5117 with fast delivery and experience Panasonic quality in your automation projects.
