Yokogawa B9627AZ Ribbon Cassette: Essential Consumable for Industrial Chart Recorders
Yokogawa B9627AZ Ribbon Cassette: Essential Consumable for Industrial Chart Recorders
Professional-grade 10-color ribbon cassette designed for Yokogawa hybrid recorders in industrial automation applications
Product Overview
The Yokogawa B9627AZ is a high-quality 10-color ribbon cassette specifically engineered for Yokogawa's DR series hybrid chart recorders. As an essential consumable component in industrial process monitoring and data acquisition systems, this ribbon cassette plays a critical role in maintaining accurate and reliable chart recording operations across various industrial sectors including manufacturing, chemical processing, power generation, and environmental monitoring.
Installation and Operation Video
Video demonstration of B9627AZ ribbon cassette installation and operation in Yokogawa chart recorders
Technical Specifications
| Parameter | Specification | Details |
|---|---|---|
| Product Type | Ribbon Cassette | 10-color thermal transfer ribbon |
| Manufacturer Part Number | B9627AZ | Original Yokogawa part number |
| Color Configuration | 10 Colors | Multi-color printing capability for clear data differentiation |
| Chart Compatibility | 344.0mm × 66' | Standard chart dimensions for Yokogawa recorders |
| Time Rotation | Variable | Configurable based on recorder settings |
| Measurement Ranges | 1 Range | (0) - (100) with uniform spacing 0 TO 100 BY 10 |
| Cross References | Multiple | 0075043, 4012 027 45498, 64-11-500V-01, 716686, 8RIBBON04-1E |
| Manufacturer | Yokogawa Electric Corporation | Global leader in industrial automation and control |
| Country of Origin | China | Manufactured to Yokogawa's global quality standards |
| Lead Time | 1-10 working days | Standard shipping and availability |
Compatible Yokogawa Recorder Models
The B9627AZ ribbon cassette is compatible with the following Yokogawa chart recorder models:
- DR130 Series - Hybrid Recorder (Stand-alone model)
- DR230 Series - Hybrid Chart Recorder
- DR240 Series - Advanced Hybrid Recorder
- DR232 Series - Expandable Hybrid Recorder
- DR231 Series - Hybrid Recorder (Stand-alone model)
- DR241 Series - Hybrid Recorder (Stand-alone model)
- DR242 Series - Multi-channel Hybrid Recorder
- DR24 Series - Legacy Chart Recorders
- HR1300 Series - High-resolution Recorders
- HR2300 Series - Advanced Recording Systems
- HR2400 Series - Professional Recording Solutions
These recorders are widely used in industrial automation environments for monitoring temperature, pressure, flow, level, and other process variables. The DR232 model, in particular, features expandable capabilities with the ability to scan up to 300 channels every 500 ms, making the B9627AZ ribbon essential for high-density data recording applications.
Key Features and Benefits
Technical Advantages
- 10-Color Printing: Enables clear differentiation of multiple process variables on a single chart
- High-Quality Thermal Transfer: Produces sharp, durable printouts that withstand industrial environments
- Precision Engineering: Designed to Yokogawa's exacting standards for reliable performance
- Easy Installation: Cassette-style design allows for quick replacement without tools
- Consistent Performance: Ensures uniform print quality throughout the ribbon lifespan
Industrial Applications
- Process Monitoring: Continuous recording of industrial process variables
- Quality Control: Documentation of production parameters for compliance
- Environmental Monitoring: Recording of emissions and environmental parameters
- Energy Management: Tracking of energy consumption patterns
- Research & Development: Data acquisition for experimental processes
Frequently Asked Questions (FAQ)
The lifespan depends on usage frequency and chart speed settings. Under normal operating conditions, each ribbon cassette typically provides several months of continuous recording. The exact duration varies based on the number of active channels and recording speed.
Most Yokogawa recorders have indicators for ribbon status. Common signs include faded print quality, inconsistent color reproduction, or complete lack of printing. Regular maintenance schedules should include ribbon replacement as a preventive measure.
While third-party alternatives exist, we recommend using genuine Yokogawa B9627AZ ribbon cassettes to ensure optimal performance, print quality, and compatibility. Non-genuine ribbons may cause print quality issues or damage to the recorder's print mechanism.
Yokogawa DR series recorders comply with CSA22.2 No.61010-1 safety standards and relevant EMC standards for industrial environments. Always refer to the specific model's user manual for complete safety information.
Store ribbon cassettes in their original packaging in a cool, dry environment away from direct sunlight and extreme temperatures. Avoid exposure to chemicals or excessive humidity to maintain print quality.
Installation and Maintenance Guidelines
Installation Procedure
- Power off the chart recorder before replacing the ribbon cassette
- Open the recorder's front panel according to the user manual instructions
- Remove the exhausted ribbon cassette by releasing the retention mechanism
- Insert the new B9627AZ ribbon cassette, ensuring proper alignment with guide pins
- Secure the cassette in place and thread the ribbon through the print mechanism
- Close the front panel and power on the recorder
- Run a test print to verify proper installation and print quality
Maintenance Recommendations
- Keep spare ribbon cassettes in inventory to prevent downtime
- Clean the print head periodically according to manufacturer guidelines
- Monitor print quality regularly and replace ribbons before complete failure
- Maintain environmental conditions within recorder specifications
- Keep detailed maintenance records for compliance and troubleshooting
External References and Documentation
Industry Applications and Use Cases
Manufacturing Industry
In manufacturing environments, the B9627AZ ribbon cassette enables continuous monitoring of production parameters such as temperature profiles in ovens, pressure in hydraulic systems, and flow rates in process lines. The 10-color capability allows simultaneous tracking of multiple variables critical to quality control.
Chemical Processing
Chemical plants utilize Yokogawa recorders with B9627AZ ribbons to document reaction temperatures, pressure conditions, and flow rates. The reliable print quality ensures accurate records for regulatory compliance and process optimization.
Power Generation
Power plants employ these recorders for monitoring turbine parameters, boiler conditions, and environmental emissions. The durable print output withstands industrial environments while providing clear, long-lasting documentation.
Environmental Monitoring
Environmental agencies and industrial facilities use these systems to record air quality parameters, water treatment processes, and emissions data. The multi-color capability facilitates easy identification of different measurement parameters.
Procurement and Supply Chain Information
The Yokogawa B9627AZ ribbon cassette is available through authorized Yokogawa distributors and industrial automation suppliers worldwide. When purchasing, ensure you're receiving genuine Yokogawa products by verifying supplier credentials and checking for authentic packaging and part numbers.
Key Procurement Considerations:
- Verify part number B9627AZ matches your requirements
- Check compatibility with your specific recorder model
- Confirm lead times based on your maintenance schedule
- Maintain appropriate inventory levels based on usage patterns
- Consider purchasing multiple units for cost efficiency
For optimal performance and reliability, we recommend sourcing B9627AZ ribbon cassettes through authorized Yokogawa channels or reputable industrial automation suppliers with proven track records in the PLC and industrial control sector.
