Omron CP1L-M60DR-D Programmable Controller: Comprehensive Guide and Technical Specifications
On this page
What is the Omron CP1L-M60DR-D?
The CP1L-M60DR-D is the mid-frame Omron SYSMAC CP1L PLC: 60 built-in I/O points — thirty-six 24 V DC inputs across channels 0-2 and twenty-four relay outputs across channels 100-102 — on a 24 V DC, 20 W CPU that programs over the front USB port and expands right-hand with CP1W units. The rear label carries the full rating block, cULus Listed 6VA2, CE, HazLoc Class I Div 2, Lot 17822S, Ver. 1.1, OMRON Corporation, made in China. The record books 3 units; four factory boxes appear in the photo set. All 10 photos and 1 video below show these exact units, refurbished with a 1-year warranty as recorded.
Part details
| Field | Value |
|---|---|
| Model | Omron SYSMAC CP1L-M60DR-D |
| I/O | 60 points: IN 00-11 (36x 24 V DC), OUT 00-07 (24x relay, channels 100-102) |
| Supply | 24 V DC, 20 W, isolated |
| Input spec | 24 V DC, 7.5 mA on 10 pts / 5 mA on 26 pts |
| Output spec | Relay: 24 V DC resistive 2 A/point; AC general 2 A/point, 4 A/common, 28 A/unit; 240 V AC ratings 180/720/1440 VA per label |
| Programming | USB behind the PERIPHERAL door |
| Expansion | EXP connector, right side |
| Lot / version | Lot 17822S, Ver. 1.1 |
| Maker | OMRON Corporation — made in China (Omron Shanghai label) |
| Approvals | cULus Listed 6VA2, CE ON1875, KC KCC-REM-OMR-CP1L-00006, HazLoc Cl I Div 2 Gp A,B,C,D / Zh2 IIC, T4 |
| Quantity | Record books 3; 4 factory boxes photographed |
| Condition | Refurbished, 1-year warranty as recorded |
| Shipping weight | 2 kg each |
Ratings are read from the rear label of the units in the photo set.
Where the M60 sits in the CP1L line
The CP1L ladder runs L (14 points), M (60) and E (40-60 types); the M60 is the built-in workhorse — enough native I/O that many machines never need an expansion rack, with the EXP connector there when they do. Thirty-six sink/source inputs handle a full sensor set; twenty-four relays switch valves, contactor coils and lamps at up to 2 A each without interposing parts, and the label's AC tables spell the group and unit totals for panel design. As with its L14 sibling, the USB port behind the PERIPHERAL door is the programming interface — CX-Programmer talks straight to it — and the BKUP LED's memory-write caution applies the same way. The four boxes in this record are Ver. 1.1, lot 17822S, with the Omron Shanghai trade label on the cartons, and they arrive refurbished — checked, cleaned and warranted for a year. For a build needing fewer points, the CP1L-M60DR-D listing covers this model and the CP1L-EM40DR-D sits between the frames.
