The IDEC LA-T10 units in this delivery are rectangular panel pushbuttons with separate lamp and contact markings. The reviewed labels specify a 24 V AC/DC lamp, while the contacts carry AC-12 125 V 0.1 A and DC-12 30 V 0.1 A markings. The lamp supply and switched-contact limits describe different parts of the assembly.
Identification and delivery details
The November 27, 2025 note records four new units and gives Japan as the origin. The first photograph shows four switches together with IDEC LA-T10 labels and JAPAN wording, consistent with the recorded model and quantity.
Each switch has a rectangular head, threaded panel-mount body, retaining hardware and rear tab terminals. The photograph supports that construction, but it does not establish the panel cutout dimensions, contact truth table or whether the actuator is momentary or maintained.
The source calls the item a reset pushbutton. Reset is a circuit role and should be checked against the machine wiring; the visible model label alone does not establish the machine's reset logic. The record's 0.5 kg weight entry has no stated basis, and no warranty term is specified.
| Item | Evidence |
|---|---|
| Visible brand and model | IDEC LA-T10 |
| Lamp marking | 24 V AC/DC |
| AC contact marking | AC-12, 125 V, 0.1 A |
| DC contact marking | DC-12, 30 V, 0.1 A |
| Origin marking | JAPAN; consistent with supply note |
| Supply | November 27, 2025; four units described new |
| Weight entry | 0.5 kg; basis unspecified |
| Actuation and contact arrangement | Not established from reviewed view |
Swipe or scroll horizontally to read the full table.
Only photograph 1 was reviewed. Seven other photographs and one video are retained without individual visual review. No contact-continuity or lamp-operation test is documented.
Matching this part
Match LA-T10, the head style and the complete lamp/contact configuration with the installed button. Confirm panel opening, retaining hardware, terminal orientation and the manufacturer's wiring information.
Keep the 24 V lamp supply separate from the AC-12 and DC-12 contact loads when specifying the circuit. Confirm the required reset action and contact arrangement against the machine drawing before replacement.
Photos and recorded media
Recorded inspection clip. The clip is retained as delivery evidence; no performance measurement is inferred from it.
Related records and products
The LAY37 pushbutton record describes a different assembly and contact reference, with no interchangeability implied. Provide the installed button and wiring through Contact us.
Request this part
Request IDEC LA-T10 with quantity, required actuator action, lamp supply and contact arrangement. Confirm current condition, availability and warranty terms.
