Product Overview
The A70P1600-4TA is a high-speed semiconductor protection fuse from Mersen's Amp-Trap® series, specifically designed for industrial automation and PLC systems requiring robust protection for sensitive electronic components.
For immediate purchase of this industrial-grade fuse, visit our official product page: Purchase A70P1600-4TA Fuse
Technical Specifications
| Parameter | Specification |
|---|---|
| Rated Current | 1600A |
| AC Voltage Rating | 700V |
| DC Voltage Rating | 650V |
| Terminal Type | Bolted Blade |
| Terminal Material | Silver-Plated Copper |
| Indication System | TA Indicator |
| Mounting Type | Bolted |
| Max Operating Temperature | 80°C |
| Series | Amp-Trap® A70P |
Key Features and Benefits
- High-Speed Protection: Ultra-rapid response time for semiconductor device protection
- Current Limiting: Effectively limits peak let-through current during fault conditions
- TA Indicator: Visual blown fuse indication for easy maintenance
- Silver-Plated Terminals: Enhanced conductivity and corrosion resistance
- Industrial Grade: Designed for harsh industrial environments
Ready to upgrade your protection system? Get Your A70P1600-4TA Fuse Today
Applications in Industrial Automation
The A70P1600-4TA is specifically designed for:
- PLC Systems: Protection of programmable logic controllers and associated power supplies
- AC/DC Drives: Semiconductor protection in variable frequency drives
- UPS Systems: Uninterruptible power supply protection
- Inverters: Power conversion equipment protection
- Reduced Voltage Motor Starters: Motor control circuit protection
- Industrial Power Distribution: High-current circuit protection
Performance Comparison
| Feature | A70P1600-4TA | Standard Fuses |
|---|---|---|
| Response Time | Ultra-fast (milliseconds) | Slow (seconds) |
| Current Limiting | Excellent | Limited |
| I²t Let-Through | Very Low | High |
| Semiconductor Protection | Optimized | Basic |
| Industrial Applications | Specialized | General Purpose |
Installation and Maintenance
For detailed installation procedures and maintenance guidelines, refer to the product documentation and ensure proper torque specifications for bolted connections.
Video demonstration: A70P1600-4TA Installation Video
Need replacement or additional units? Order A70P1600-4TA Fuses Now
Frequently Asked Questions
Industry Standards and Certifications
The A70P1600-4TA complies with relevant industrial standards for semiconductor protection fuses and is manufactured by Mersen, a globally recognized leader in electrical protection solutions.
For technical specifications, application notes, and detailed performance data, consult the manufacturer's documentation and ensure compliance with local electrical codes and standards.
