872C-D8NP18-E2: delivery record

This Allen-Bradley 872C-D8NP18-E2 record covers ten inductive proximity sensors described as new, with a one-year warranty, dated 29 May 2026. The reviewed packaging specifies 10-30 VDC input, a load below 200 mA, PNP output and OUTPUT: NC. The NC marking takes precedence over the normally-open claim in the source description.

Identification and delivery details

The first photograph shows a threaded metal sensor, two mounting nuts, a black sensing face and a cable with exposed brown, blue and black conductor ends. The second gives a readable bag presentation labelled Allen-Bradley and Rockwell Automation with the complete 872C-D8NP18-E2 code.

The bag states an 8 mm sensing distance and IP67. It prints the unshielded wording as USSHIELDED. These are packaging specifications, not results from a target-distance or ingress test. The visible origin line reads MADE IN THE DOMINICAN RE; the source note gives the Dominican Republic.

The packaging includes a connector-style diagram while the first photograph shows cable conductor ends. Confirm the delivered termination and circuit diagram before replacement rather than inferring a pin assignment from the bag. The record lists 0.5 kg without a packing basis; no per-sensor measured weight is established.

Swipe or scroll horizontally to read the full table.

Photographs 1 and 2 were reviewed; three further source images are retained with neutral captions. The old source description says PNP NO, while the photographed bag says NC. The bag wording is reported without treating it as a functional output test.

Matching this part

Use the full 872C-D8NP18-E2 code and require confirmation of the normally-closed output. Check the actual cable or connector arrangement against the installed sensor and controller input. Do not choose an adjacent code solely because it shares the 872C family or an 8 mm range.

Confirm sensing target, mounting clearances and supply/load conditions from the applicable documentation. The full-model catalogue search, including compact punctuation variants, found no clear matching product; no nearby sensor link is substituted.
