CKD A4F010-06 Solenoid Valve: Complete Technical Guide for Industrial Automation
CKD A4F010-06 Solenoid Valve: Professional Industrial Automation Solution
High-performance 5-port pilot-operated solenoid valve for demanding industrial applications
Product Overview
The CKD A4F010-06 is a premium 5-port pilot-operated solenoid valve designed for industrial automation applications. This high-performance valve offers exceptional reliability and versatility across various industrial environments, making it an ideal choice for PLC-controlled pneumatic systems.
Product Gallery
Technical Specifications
| Parameter | Specification | Details |
|---|---|---|
| Model Number | A4F010-06 | Part of CKD 4F0 Series |
| Valve Type | 5-Port Solenoid Valve | Pilot operated, soft spool design |
| Working Fluid | Compressed Air | Standard / Oil-Free specification available |
| Max Working Pressure | 1.0 MPa (≈150 psi, 10 bar) | Industrial standard pressure rating |
| Voltage Options | DC24V, AC200V | Multiple electrical configurations |
| Actuation Type | Single Solenoid | 2-position single operation |
| Status at Power Off | Self-reset (differential pressure return) | Automatic reset functionality |
| Mounting | Direct Mounting | 3-ø4.5 mm mounting holes |
| Weight | 0.21 lbs (approx. 95g) | Lightweight industrial design |
Key Features & Benefits
High Performance Operation
Pilot-operated soft spool design ensures smooth and reliable operation even in demanding industrial environments.
Versatile Applications
Suitable for wide variety of industrial fields with excellent total performance and selection options.
Lubrication Flexibility
Possible to use hard and without lubrication, providing operational flexibility for different maintenance requirements.
Compact Design
Space-efficient footprint with dimensions optimized for industrial automation panel mounting.
Industrial Applications
- Manufacturing Automation: Assembly lines, robotic systems, material handling
- Process Control: Chemical processing, food and beverage, pharmaceutical
- Packaging Machinery: Filling, sealing, and packaging equipment
- Automotive Industry: Production lines, testing equipment
- PLC Integration: Direct integration with industrial control systems
Frequently Asked Questions (FAQ)
The maximum working pressure is 1.0 MPa (approximately 150 psi or 10 bar), making it suitable for most industrial pneumatic applications.
Yes, the A4F010-06 is designed to operate both with and without lubrication, providing flexibility for different maintenance requirements and application needs.
The valve is available in multiple voltage configurations including DC24V and AC200V variants to suit different industrial power systems.
The self-reset (differential pressure return) feature ensures the valve returns to its default position automatically when power is removed, using differential pressure for reliable reset operation.
The valve features direct mounting with 3-ø4.5 mm mounting holes. Ensure proper air filtration and follow manufacturer guidelines for piping tightening torque specifications.
Yes, the A4F010-06 is specifically designed for integration with PLC industrial automation systems, making it ideal for automated control applications.
Quality & Reliability Assurance
Industry Standards: CKD valves are manufactured to meet international industrial standards for pneumatic components.
Technical Support: Comprehensive documentation and technical support available through CKD's global network.
Application Versatility: Proven performance across multiple industrial sectors including manufacturing, automotive, and process industries.
Reliability: Designed for long service life with minimal maintenance requirements in demanding industrial environments.
Installation & Maintenance Guidelines
- Always read the instruction manual thoroughly before installation
- Ensure proper air filtration and moisture removal in the pneumatic system
- Do not apply external force to solenoid components during installation
- Follow specified piping tightening torque requirements
- Avoid placing insulating covers on the entire valve or coil section
- Regular inspection for sediment, debris, or corrosion in the flow path
Technical References & Documentation
For detailed technical specifications, installation manuals, and application notes, refer to:
- CKD Official Documentation: 4F**0E Series Technical Manual
- Mounting and Installation Guide: CKD Installation Manual
- Industry Applications: Available through authorized CKD distributors
