Mitutoyo 7011S-10 Magnetic Stand: Precision Measurement Solution for Industrial Automation
Mitutoyo 7011S-10 Magnetic Stand: Precision Measurement Solution for Industrial Automation
The Mitutoyo 7011S-10 represents the gold standard in magnetic measurement stands, offering exceptional precision and reliability for industrial automation applications requiring accurate dimensional measurement and quality control.
Product Overview
The Mitutoyo 7011S-10 is a universal magnetic stand designed specifically for precision measurement applications in industrial automation environments. This professional-grade instrument features fine adjustment capabilities and robust construction, making it ideal for quality control departments, manufacturing facilities, and research laboratories where accurate dimensional measurements are critical.
Product Demonstration
Key Features and Benefits
Precision Fine Adjustment
Advanced fine adjustment mechanism allows for micro-positioning of measurement instruments with exceptional accuracy, enabling precise dimensional measurements in demanding industrial environments.
High Magnetic Clamping Force
600N clamping force ensures secure mounting on ferromagnetic surfaces, providing stability during measurement operations and preventing accidental displacement.
Universal Compatibility
Supports multiple holding stem diameters including ø4mm, ø8mm, and ø9.53mm (3/8"), making it compatible with a wide range of dial indicators and test indicators.
Instant ON/OFF Switching
Quick-release magnetic base with convenient ON/OFF switch enables rapid mounting and dismounting, improving workflow efficiency in production environments.
Technical Specifications
| Parameter | Specification | Details |
|---|---|---|
| Applicable Holding Stem Diameter | ø4mm, ø8mm, ø9.53mm | Universal compatibility with standard measurement tools |
| Magnetic Clamping Force | 600N | High holding power for stable operation |
| Base Dimensions | 59 x 50 x 55 mm | Compact design for versatile positioning |
| Total Height | 232 mm | Extended reach capability |
| Fine Adjustment | Included | Precision positioning capability |
| Dovetail Groove | Standard | Enhanced mounting flexibility |
| Cross Arm Design | Standard | Improved stability and reach |
Industrial Applications
The Mitutoyo 7011S-10 magnetic stand is essential equipment in various industrial automation scenarios:
- Quality Control Stations: Used for dimensional inspection and tolerance verification in manufacturing processes
- CNC Machine Integration: Provides stable mounting for measurement instruments during automated machining operations
- Research and Development: Supports precision measurement in laboratory and prototyping environments
- Automotive Manufacturing: Critical for component inspection and assembly verification
- Aerospace Industry: Ensures dimensional accuracy in high-precision manufacturing
Frequently Asked Questions
The stand is compatible with dial indicators, dial test indicators, and other measurement tools with stem diameters of ø4mm, ø8mm, and ø9.53mm (3/8").
The magnetic base features a 600N clamping force with an ON/OFF switch for controlled engagement. The design ensures secure mounting while preventing damage to sensitive measurement instruments.
While primarily designed for ferromagnetic surfaces, the stand can be used with appropriate adapters or mounting plates for non-magnetic surfaces.
The fine adjustment mechanism requires minimal maintenance. Regular cleaning and occasional lubrication with appropriate instrument oil will ensure smooth operation and longevity.
Yes, the 7011S-10's stable mounting and precise adjustment capabilities make it suitable for integration into automated measurement and inspection systems.
Industry Standards and Certifications
Mitutoyo products are manufactured according to international quality standards and are widely recognized in industrial automation for their reliability and precision. The 7011S-10 magnetic stand meets the demanding requirements of ISO 9001 quality management systems and is trusted by leading manufacturers worldwide.
Conclusion
The Mitutoyo 7011S-10 magnetic stand represents the pinnacle of precision measurement support equipment for industrial automation applications. With its robust construction, fine adjustment capabilities, and universal compatibility, it provides the foundation for accurate dimensional measurement in demanding manufacturing environments. Whether used in quality control, research and development, or production line applications, the 7011S-10 delivers the reliability and precision that professionals in the PLC industrial automation field demand.
