Fuji IGBT Module 150A 1200V Fast

Fuji IGBT Module 150A 1200V Fast

$467.63 USD
$467.63 USD $467.63 USD
Sale Ausverkauft
Versand wird beim Checkout berechnet
Condition new
MPN 7MBP150RA120-05
type IGBT Module
model 7MBP150RA120-05
current 150A
voltage 1200V
condition 150A, 1200V
performance Fast
