Mitsubishi FX3G 14MT/ES-A PLC: Comprehensive Guide to Features, Applications, and Specifications
Mitsubishi FX3G 14MT/ES-A PLC: The Ultimate Compact Automation Solution
The Mitsubishi FX3G 14MT/ES-A represents the pinnacle of compact, high-performance programmable logic controllers designed for industrial automation applications. This all-in-one unit combines power supply, CPU, and I/O capabilities in a single, efficient package.
View Product Details & PurchaseProduct Overview
The Mitsubishi FX3G 14MT/ES-A is a versatile PLC unit featuring 8 input points and 6 output points, making it ideal for small to medium-scale automation projects. With its transistor output configuration and 100-240VAC power supply, this unit offers exceptional flexibility and reliability in industrial environments.
Product demonstration video showing the FX3G 14MT/ES-A in operation
Key Features and Technical Specifications
Core Features
- All-in-One Design: Integrated power supply, CPU, and I/O in a single compact unit
- High-Speed Processing: Advanced CPU with fast execution times for real-time control
- Built-in Positioning Control: Integrated positioning outputs for motion control applications
- Flexible I/O Configuration: 8 inputs / 6 outputs with transistor output type
- Wide Power Supply Range: 100-240VAC operation for global compatibility
- Continuous Scanning Function: Customizable operation cycles for optimized performance
| Specification | Details |
|---|---|
| Model Number | FX3G-14MT/ES-A |
| Input Points | 8 points (S/S, 24VDC) |
| Output Points | 6 points (Transistor) |
| I/O Type | Input: Sink/Source | Output: Transistor |
| Power Supply | 100 to 240VAC |
| Control Points | 16-256 points (expandable) |
| Communication | Built-in MODBUS serial communication capability |
| Automation Grade | High |
| Connectivity Type | Wired |
| Drive Type | Digital |
Applications and Use Cases
Industrial Applications
The Mitsubishi FX3G 14MT/ES-A is perfectly suited for a wide range of industrial automation applications:
- Packaging Machinery: Control of conveyors, fillers, and sealing systems
- Material Handling: Automated guided vehicles and conveyor systems
- Process Control: Temperature, pressure, and flow regulation
- Assembly Lines: Robotic arm coordination and part positioning
- Building Automation: HVAC control, lighting systems, and access control
- Water Treatment: Pump control and chemical dosing systems
Technical Advantages
The FX3G series offers several technical advantages over competing PLC systems:
- Compact Footprint: Space-efficient design ideal for control panels with limited space
- Easy Programming: Compatible with Mitsubishi's GX Works2 software
- Reliable Performance: Industrial-grade components for 24/7 operation
- Expandability: Support for additional I/O modules and special function units
- Energy Efficient: Low power consumption design
Documentation and Support
The Mitsubishi FX3G 14MT/ES-A comes with comprehensive documentation including:
- Hardware Manual
- Positioning Control Edition User's Manual
- Basic & Applied Instructions Edition Programming Manual
- MODBUS Serial Communication Edition User's Manual
- Installation and Configuration Guides
For immediate purchase and detailed technical specifications, visit our product page: Mitsubishi FX3G 14MT/ES-A PLC
Frequently Asked Questions (FAQ)
The FX3G-14MT/ES-A features 8 inputs and 6 transistor outputs, while other models in the series may have different I/O configurations or output types (relay vs transistor). The "ES-A" suffix indicates specific regional compliance standards.
Yes, the FX3G series supports expansion modules that can increase the total I/O capacity up to 256 points. Various expansion modules are available for additional digital I/O, analog I/O, and special functions.
Mitsubishi's GX Works2 software is recommended for programming the FX3G series. This software provides ladder logic programming, function block diagrams, and structured text capabilities.
Yes, the unit includes built-in high-speed counters and positioning outputs, making it suitable for applications requiring precise timing and motion control.
The FX3G-14MT/ES-A supports MODBUS serial communication and can interface with various industrial networks through additional communication modules.
You can purchase the Mitsubishi FX3G 14MT/ES-A directly from our authorized distributor at https://koeed.com/products/mitsubishi-plc-fx3g-14mt-es-a-base-unit-fx3g14mtesa-plc-processors-new-in-box-s. All units come with manufacturer warranty and technical support.
Industry Recognition and Certifications
The Mitsubishi FX3G series has received widespread industry recognition for its reliability and performance. Key certifications include:
- CE Marking for European market compliance
- UL Listing for North American standards
- ISO 9001 quality management certification
- Industrial-grade environmental ratings (operating temperature: 0-55°C)
For engineers and system integrators looking for a reliable, compact PLC solution, the Mitsubishi FX3G 14MT/ES-A offers exceptional value and performance. Visit our product page to learn more about pricing, availability, and technical specifications.
Comparison with Similar Products
| Feature | FX3G-14MT/ES-A | Competitor A | Competitor B |
|---|---|---|---|
| I/O Points | 14 (8 In / 6 Out) | 10-16 points | 12-20 points |
| Output Type | Transistor | Relay/Transistor | Relay only |
| Power Supply | 100-240VAC | 24VDC only | 100-240VAC |
| Built-in Positioning | Yes | No | Optional |
| High-Speed Counters | Built-in | Additional module | Built-in |
| Communication | MODBUS built-in | Additional module | Ethernet optional |
All units are new in box with full manufacturer warranty
