6GHz 3.5mm Male Connector Set for Industrial Automation and PLC Applications
6GHz 3.5mm Male Connector Set for Industrial Automation
High-performance RF connector solution for PLC systems and industrial applications
Product Overview
The 6GHz 3.5mm Male 3-Piece Connector Set represents a premium-grade RF connector solution specifically engineered for industrial automation and PLC applications. This comprehensive set provides reliable, high-frequency connectivity for demanding industrial environments where signal integrity and durability are paramount.
Designed to operate at frequencies up to 6GHz, these connectors offer exceptional performance for measurement, instrumentation, and communication systems in factory automation, process control, and industrial networking applications.
Product Images and Video
Product Demonstration Video
This demonstration video showcases the installation process and key features of the 6GHz 3.5mm Male Connector Set.
Technical Specifications
| Parameter | Specification | Value/Description |
|---|---|---|
| Frequency Range | Maximum Operating Frequency | Up to 6 GHz |
| Connector Type | Interface Standard | 3.5mm Male (3-piece set) |
| Impedance | Characteristic Impedance | 50 Ω (Standard for RF applications) |
| Voltage Rating | Maximum Working Voltage | 500 V RMS (typical) |
| Temperature Range | Operating Temperature | -55°C to +125°C |
| Durability | Mating Cycles | ≥ 500 cycles |
| Contact Resistance | Center Contact | < 5 mΩ |
| Insulation Resistance | Minimum Value | > 5,000 MΩ |
| VSWR | Voltage Standing Wave Ratio | < 1.15:1 up to 6 GHz |
Key Features and Benefits
- High-Frequency Performance: Optimized for applications up to 6GHz with minimal signal loss
- Industrial Durability: Robust construction withstands harsh industrial environments
- Precision Engineering: Tight tolerances ensure reliable connections and signal integrity
- Quick Installation: Designed for easy installation in PLC cabinets and industrial equipment
- Compatibility: Compatible with SMA connectors for versatile application integration
- Corrosion Resistance: Gold-plated contacts prevent oxidation and ensure long-term reliability
Industrial Applications
PLC Systems
Signal transmission between PLC modules and field devices
Industrial Networking
High-speed data communication in factory automation networks
Test & Measurement
Precision measurement equipment and instrumentation
Process Control
Control signal transmission in industrial process systems
Building Automation
Lighting systems and building management systems
Robotics
Signal transmission in robotic arms and automation equipment
Frequently Asked Questions (FAQ)
The 6GHz rating ensures superior signal integrity at higher frequencies, making these connectors ideal for modern industrial applications that require high-speed data transmission and precise measurement capabilities.
Yes, 3.5mm connectors are mechanically compatible with SMA connectors. However, 3.5mm connectors offer better performance at higher frequencies and are generally more durable for industrial applications.
These connectors feature robust construction, corrosion-resistant materials, and reliable performance characteristics that meet the demanding requirements of industrial PLC environments, including vibration resistance and long-term reliability.
The connectors are rated for a minimum of 500 mating cycles, ensuring long-term reliability in applications where connections may need to be made and broken multiple times.
These connectors operate reliably in temperatures ranging from -55°C to +125°C, making them suitable for both extreme cold and hot industrial environments.
Quality and Reliability Metrics
Industry Standards and Compliance
Our 6GHz 3.5mm Male Connector Set complies with relevant industry standards including:
- IEC 61169-16: RF connectors - Part 16: Sectional specification for RF coaxial connectors with inner diameter of outer conductor 3.5 mm (3.5/1.6)
- MIL-PRF-39012: Military specification for RF coaxial connectors
- ISO 9001:2015 Quality Management System certification
- RoHS compliance for environmental safety
Installation Guidelines
For optimal performance and longevity, follow these installation guidelines:
- Ensure proper cable preparation with clean, straight cuts
- Use appropriate torque wrenches for connector assembly (typically 8-12 in-lbs)
- Inspect connectors for damage before installation
- Apply minimal, appropriate lubricant if specified
- Perform continuity and insulation resistance tests after installation
- Regularly inspect connections in high-vibration environments
Technical Support and Resources
For technical support, installation guidance, or additional specifications, please contact our engineering team. We provide comprehensive documentation including detailed datasheets, application notes, and installation guides to ensure successful integration into your industrial automation systems.
