Autonics FX4S-1P4: Comprehensive Guide to the 4-Digit Counter/Timer with Relay Output
Autonics FX4S-1P4: The Ultimate 4-Digit Counter/Timer for Industrial Automation
The Autonics FX4S-1P4 represents a sophisticated solution for industrial counting and timing applications, combining versatility with reliable performance in a compact 1/16 DIN form factor.
Product Overview
The FX4S-1P4 from Autonics is a high-performance 4-digit counter and timer designed for industrial automation applications. This versatile device features dual functionality as both a counter and timer, making it an essential component in various industrial control systems. With its compact 48x48mm DIN rail mounting design and multiple output options, it provides exceptional flexibility for automation engineers.
Product Images
Product Demonstration Video
Key Features and Technical Specifications
Dual Functionality
The FX4S-1P4 offers switchable operation between counter and timer modes using a convenient DIP switch, providing maximum flexibility for different industrial applications.
High-Speed Counting Capabilities
With multiple counting speed options (1 cps, 30 cps, 2 kcps, and 5 kcps), this device can handle a wide range of industrial counting requirements from slow mechanical operations to high-speed electronic counting.
Advanced Display System
Features a high-visibility LED display with red characters measuring 7.60mm in height, ensuring excellent readability in various industrial lighting conditions.
| Specification Category | Details |
|---|---|
| Model Number | FX4S-1P4 |
| Manufacturer | Autonics |
| Display Type | LED - Red Characters |
| Display Height | 0.299" (7.60mm) |
| Form Factor | 1/16 DIN (48x48mm) |
| Power Supply | 100-240VAC~ 50/60Hz |
| Input Type | Voltage |
| Output Type | Relay and Solid State (NPN) |
| Counting Speeds | 1 cps / 30 cps / 2 kcps / 5 kcps |
| Time Operation | POWER ON START |
| Output Operation | POWER ON DELAY, FLICKER |
| External Power Supply | Max. 12VDC ±10% 50mA |
| Analog Output | 0-10Vdc control analog output |
| Secondary Output | Relay control output |
| Display Colors | 11mm orange and 7mm green indicators |
Industrial Applications
The FX4S-1P4 is ideally suited for various industrial applications including:
- Production Line Counting: Monitoring production quantities and batch counting
- Process Timing: Controlling machine cycle times and process durations
- Packaging Systems: Counting packaged items and controlling packaging cycles
- Material Handling: Tracking material flow and conveyor operations
- Quality Control: Monitoring test durations and counting test cycles
- Energy Management: Timing equipment operation for energy efficiency
Comparison with Similar Products
| Feature | FX4S-1P4 | Standard Counters | Basic Timers |
|---|---|---|---|
| Dual Functionality | ✓ Counter & Timer | ✗ Counter only | ✗ Timer only |
| Counting Speeds | 4 selectable speeds | Single speed | N/A |
| Output Options | Relay + NPN + Analog | Single output | Single output |
| Power Supply Range | 100-240VAC | Fixed voltage | Fixed voltage |
| Display Size | 7.60mm LED | 5-6mm typical | 5-6mm typical |
| Form Factor | 1/16 DIN (48x48mm) | Various sizes | Various sizes |
Frequently Asked Questions (FAQ)
Trust Metrics and Industry Recognition
Industry Standard
1/16 DIN form factor compliant with international standards
Wide Voltage Range
100-240VAC compatibility for global applications
Multiple Outputs
Relay, NPN, and analog outputs for versatile integration
High-Speed Operation
Up to 5 kcps counting speed for demanding applications
External References and Technical Resources
The FX4S-1P4 is available through major industrial automation distributors including:
- DigiKey Electronics: Official Product Page
- Quantum First Automation: Technical Specifications
- Applied Automation Controls: Application Notes
- Marshall Wolf Automation: Product Documentation
- Techni-Tool: Purchase Information
Installation and Maintenance Guidelines
For optimal performance and longevity of your FX4S-1P4:
- Ensure proper DIN rail mounting with secure connections
- Follow recommended wiring practices as shown in the provided images
- Maintain clean power supply within specified voltage ranges
- Regularly inspect connections and display functionality
- Keep the device in appropriate environmental conditions (temperature, humidity)
- Refer to the demonstration video for proper setup procedures
Conclusion
The Autonics FX4S-1P4 represents a sophisticated and versatile solution for industrial counting and timing applications. Its dual functionality, multiple output options, wide voltage compatibility, and compact design make it an excellent choice for automation engineers seeking reliable performance in diverse industrial environments. With its high-speed counting capabilities and excellent display visibility, this device stands out as a premium solution in the 1/16 DIN counter/timer category.
Whether you're implementing new automation systems or upgrading existing equipment, the FX4S-1P4 offers the flexibility, reliability, and performance needed for modern industrial applications. Its comprehensive feature set and industry-standard design ensure seamless integration into various control systems while providing accurate counting and timing functions for critical industrial processes.
