Mitsubishi FX3SA-10MR-CM PLC: Compact Industrial Automation Solution for Small to Medium Applications
Mitsubishi FX3SA-10MR-CM PLC: Compact Industrial Automation Solution
The Mitsubishi FX3SA-10MR-CM is a compact, cost-effective programmable logic controller designed for small to medium industrial applications requiring reliable automation control.
View Product Details →Product Overview
The Mitsubishi FX3SA-10MR-CM represents the latest evolution in Mitsubishi's compact PLC series, combining the proven reliability of the FX1S platform with enhanced features and performance. This all-in-one unit integrates CPU, power supply, and I/O in a compact 100x90x49mm package, making it ideal for space-constrained applications.
Product Demonstration Video
Watch the FX3SA-10MR-CM in action and learn about its key features
Technical Specifications
| Parameter | Specification |
|---|---|
| Model | FX3SA-10MR-CM |
| Manufacturer | Mitsubishi Electric |
| Power Supply | 100-240V AC |
| Input Points | 36 points |
| Output Points | 24 points |
| Output Type | Relay |
| Dimensions (W×H×D) | 100 × 90 × 49 mm |
| Weight | 0.35 kg |
| Power Consumption | 35W |
| Program Memory | 16K steps |
| Auxiliary Relays | 7,680 total (384 general, 1,152 EEPROM latched, 6,144 general/optional latched) |
| Programming Software | GX Works3 compatible |
Key Features & Benefits
Compact Design
The FX3SA-10MR-CM maintains the compact footprint of the FX1S series while adding enhanced functionality. Its small size (100x90x49mm) makes it perfect for applications where space is limited.
Integrated Architecture
This all-in-one unit combines CPU, power supply, and I/O in a single package, simplifying installation and reducing wiring complexity. The built-in power supply supports 100-240V AC input, providing flexibility for different power systems.
Relay Output Configuration
The "MR" designation indicates relay outputs, which provide electrical isolation and can switch both AC and DC loads. This makes the FX3SA-10MR-CM versatile for various industrial applications.
Enhanced Memory Capacity
With 16K steps of program memory and extensive auxiliary relay capacity (7,680 total), this PLC can handle complex control sequences while maintaining fast execution speeds.
Programming Flexibility
Compatible with Mitsubishi's GX Works3 software, the FX3SA-10MR-CM supports multiple programming languages including ladder logic, function block diagrams, and structured text.
Comparison with Other FX3SA Models
| Model | I/O Points | Output Type | Power Supply | Dimensions |
|---|---|---|---|---|
| FX3SA-10MR-CM | 10 (6 In / 4 Out) | Relay | 100-240V AC | 100×90×49mm |
| FX3SA-20MR-CM | 20 (12 In / 8 Out) | Relay | 100-240V AC | 100×90×49mm |
| FX3SA-30MR-CM | 30 (18 In / 12 Out) | Relay | 100-240V AC | 100×90×49mm |
| FX3SA-10MT-CM | 10 (6 In / 4 Out) | Transistor | 100-240V AC | 100×90×49mm |
Industrial Applications
The Mitsubishi FX3SA-10MR-CM is ideally suited for various industrial automation applications including:
- Packaging Machinery: Control of conveyors, fillers, and sealing equipment
- Material Handling: Automated guided vehicles (AGVs), sorting systems
- Building Automation: HVAC control, lighting systems, access control
- Small Manufacturing Cells: CNC machine control, assembly line automation
- Water Treatment: Pump control, valve sequencing, level monitoring
- Food & Beverage Processing: Batch processing, mixing control, temperature regulation
For specific application requirements, visit our product page for detailed configuration options.
Industry Recognition & Trust Metrics
The Mitsubishi FX series has been a trusted name in industrial automation for decades, with millions of units deployed worldwide. Key trust indicators include:
- ISO 9001 Certified Manufacturing: All Mitsubishi PLCs are produced in ISO-certified facilities
- Global Support Network: Technical support available in over 100 countries
- Proven Reliability: MTBF (Mean Time Between Failures) exceeding 100,000 hours
- Industry Standards Compliance: Meets IEC 61131-3 programming standards
- Safety Certifications: CE, UL, and other international safety approvals
According to industry reports, Mitsubishi Electric holds approximately 15% of the global PLC market share, demonstrating widespread industry acceptance.
Frequently Asked Questions
The "MR" designation indicates relay outputs, while "MT" indicates transistor outputs. Relay outputs provide electrical isolation and can switch both AC and DC loads, while transistor outputs are faster and better suited for DC switching applications.
The FX3SA-10MR-CM is fully compatible with Mitsubishi's GX Works3 software, which supports ladder logic, function block diagrams, structured text, and sequential function chart programming languages.
Yes, the FX3SA series supports expansion modules for additional digital I/O, analog I/O, communication interfaces, and special function modules. Check the product specifications for compatible expansion options.
The FX3SA-10MR-CM operates within a temperature range of 0°C to 55°C (32°F to 131°F) with proper installation and ventilation.
The FX3SA maintains the compact size of the FX1S while offering enhanced features including larger program memory, more auxiliary relays, improved processing speed, and compatibility with modern programming software.
The FX3SA-10MR-CM supports various communication options including RS-232, RS-422, RS-485, and Ethernet (with appropriate communication modules). It also supports Mitsubishi's proprietary MELSEC communication protocol.
Installation & Maintenance Guidelines
For optimal performance and longevity of your FX3SA-10MR-CM PLC:
- Proper Mounting: Install in a well-ventilated location away from heat sources and direct sunlight
- Electrical Protection: Use appropriate circuit protection and grounding according to local electrical codes
- Environmental Considerations: Protect from excessive dust, moisture, and corrosive atmospheres
- Regular Maintenance: Periodically check connections, clean ventilation areas, and verify proper operation
- Backup Procedures: Regularly backup program memory and configuration settings
For detailed installation instructions and wiring diagrams, refer to the official Mitsubishi documentation or consult our technical support team through the product support page.
Conclusion
The Mitsubishi FX3SA-10MR-CM represents an excellent balance of compact design, reliable performance, and cost-effectiveness for small to medium industrial automation applications. With its integrated architecture, flexible programming options, and proven Mitsubishi reliability, this PLC provides a solid foundation for automation projects across various industries.
Whether you're upgrading existing equipment or implementing new automation solutions, the FX3SA-10MR-CM offers the features and reliability needed for successful industrial control applications. For pricing, availability, and technical support, visit our official product page.
