Description
Technical specifications for EL1804
| Key | Value |
|---|---|
| Current Range | 4-20mA |
| Dimensions | 120 x 70 x 100 mm |
| Connection | Screw connection terminal |
| Operating Temperature | 0 to 55 °C |
| Compatibility | Beckhoff Bus Terminal System |
| Model | EL1804 |
| Type | Analog Input Terminal |
| Input Channels | 4 |
| Voltage Range | 0-10V |
| Resolution | 16-bit |
| Weight | 0.2 kg |
Description
The Beckhoff EL1804 Analog Input Terminal Module is a top-tier solution for collecting analog signals. Designed to efficiently handle a wide input voltage range from 0-10V and current range from 4-20mA, the EL1804 ensures high-resolution analog data with its 16-bit precision. Weighing just 0.2 kg and with compact dimensions of 120 x 70 x 100 mm, the EL1804 is perfect for various installations. The operating temperature range of 0 to 55 °C provides versatility in different environments. With its compatibility with the Beckhoff Bus Terminal System, the EL1804 is a reliable choice for any automation task, making it an invaluable component in modern control systems.
Alternative names
- EL1800
- EL1805
- B3ckhoff EL1804
- Beckofh EL1804
- Becnhoff EL1804
- El1804
