1PCS NEW FOR Ferraz Shawmut SC33AR69V13CTF A1046960 1250A 690V Fuse

1PCS NEW FOR Ferraz Shawmut SC33AR69V13CTF A1046960 1250A 690V Fuse

$711.64 USD
$711.64 USD $711.64 USD
Sale Sold out
Shipping calculated at checkout.
MPN SC33AR69V13CTF A1046960
View full details

  • step 1: Quote Or Shop Now

    You can place an order directly or contact us via email and whatsapp for a quote

  • step 2: Confirmation and delivery

    After placing an order, we will contact you by email or WhatsApp within three days to provide photos and videos of the product for confirmation and then ship it.

Customers are saying

4.99 ★ (1084)
Verified

Engineer's Quick Brief

  • Ultra-Fast Semiconductor Protection: Designed specifically as a square body PSC high-speed fuse to safeguard heavy-duty rectifiers, VFDs, and power converters against catastrophic short-circuit clearing events.
  • Extreme Interrupting Rating: Engineered for direct high-capacity industrial grid deployment, safely managing severe sub-millisecond faults under 690V AC operational limits.
  • Minimized Power Dissipation: Built with pure silver fuse elements and superior structural thermal cooling metrics to guarantee reduced voltage drop and lower ambient heat generation inside tight electrical enclosures.

The Ferraz Shawmut SC33AR69V13CTF (global catalog tracking reference A1046960) is a high-performance, industrial-grade high-speed square body fuse built for the definitive defense of solid-state electronics. Rated at a robust current capacity of 1250A and a maximum working potential of 690V, this specialized semiconductor protection fuse limits let-through energy values ($I^2t$) to protect sensitive components like thyristors, IGBTs, and SCR arrays. Now manufactured under the premium Mersen umbrella, the SC33AR69V13CTF features reliable blade type or bolt-down terminal configurations, providing clean integration into low-latency electrical distribution networks.

Technical Specifications

Engineering Parameter Technical Classification Operational Value
Brand Manufacturer OEM Brand Heritage Ferraz Shawmut (Mersen)
Model Number Factory Catalog Part Identifier SC33AR69V13CTF
Smart Product Code Unique Material ID Reference A1046960
Body Size Configuration Physical Frame Scale Standard Size 33 Architecture
Rated Current ($I_n$) Continuous Thermal Amperage Capacity 1250A
Rated Voltage ($U_n$) Maximum Dielectric Arc Limit 690V AC
Fuse Class Utilization Operational Tripping Slopes Category aR (Partial Range High-Speed Semiconductor Protection)
Terminal Style Electrical Interface Integration Type Flush-end blade tracking / End-mounting configuration style
Interrupting Rating (Breaking Capacity) Maximum Safely Cleared Fault Current 200 kA at 690V AC (Standard Operational Boundary)
Body Material Matrix Structural Enclosure Substrate High-strength ceramic body filled with high-purity quartz sand

Application Matrix

Target Industrial System Deployment Purpose Engineering Value Delivered
High-Power Variable Frequency Drives (VFD) DC bus short-circuit isolation Fast sub-millisecond reaction prevents costly downstream inverter IGBT bridge damage during overcurrent spikes.
Industrial DC Rectifiers Solid-state power device protection Ensures isolation of localized component failure modes before faults can propagate into multi-phase industrial transformers.
UPS Systems & Soft Starters Critical grid interface shielding Maintains precise low thermal let-through energy thresholds ($I^2t$) to shield delicate silicone control paths.

Koeed B2B Tool: High-Speed Fuse Thermal Derating Calibrator

High-speed aR semiconductor fuses operate in demanding closed enclosures. Use this technical configuration utility to calculate the corrected operational continuous current limit based on environmental factors like ambient temperature and cooling air speed velocity inside your power panel.

Maximum Continuous Safe Operating Current ($I_{ob}$):
1187.5 A
Calculated using standardized thermal equations under standard IEC enclosures.

Troubleshooting & FAQ

Q1: Can an aR class high-speed fuse like the SC33AR69V13CTF be used for standard motor branch circuit overload shielding?

No. Fuses marked with an **aR** classification provide partial-range protection optimized solely for short-circuit faults inside high-speed semiconductor environments. They cannot manage sustained low-level thermal overloads. For standard line-level installations, integrate an autonomous thermal overload relay or combine with a gG/gM class distribution fuse network.

Q2: Why must high-speed semiconductor fuses be torque-checked during panel maintenance?

Because semiconductor protection involves extremely high running currents up to 1250A. Any microscopic air gap or loose mounting bolt on the Size 33 flush-end terminals introduces parasitic contact resistance. This localized resistance acts as a heater, inducing premature element aging, nuisance trippings, and accelerated thermal fatigue.

Q3: What causes a high-speed square body fuse to disfigure or show signs of external blackening?

This point points toward heavy arc energy dissipation inside the chamber during high-power short circuit extraction. The specialized high-purity quartz sand filling vaporizes to absorb the thermal energy and safely extinguish the electrical arc plasma. If external ceramic cracking or burning is visible, inspect all adjacent power semiconductor components for failure modes before mounting a replacement unit.

Cross-Reference Guide

When executing maintenance cross-referencing or designing upgrade specifications, the following models feature corresponding form factors and electrical compatibility parameters:

  • Mersen / Ferraz Shawmut Legacy Reference: Replaces catalog part numbers matching the format PC33UD69V1250TF or specific variants within the A1046960 high-speed engineering ledger.
  • Industry Competitor Alternates: Direct functional physical alignment with Size 3 high-speed square body flush-end fuses from Bussmann (such as 170M6416 or equivalent 1250A 690V AC series ratings). Always cross-check the let-through $I^2t$ parameters prior to hot-swapping operational industrial panels.
