DC24V 90W ZD Zhongda Z5D90-24GU-30S Motor for Various Applications

DC24V 90W ZD Zhongda Z5D90-24GU-30S Motor for Various Applications

$480.00 USD
$480.00 USD $480.00 USD
Sale Sold out
Shipping calculated at checkout.
MPN Z5D90-24GU-30S
Size Not specified
Model Z5D90-24GU-30S
Power 90W
Weight Not specified
Voltage DC24V
Dimensions Not specified
View full details

  • step 1: Quote Or Shop Now

    You can place an order directly or contact us via email and whatsapp for a quote

  • step 2: Confirmation and delivery

    After placing an order, we will contact you by email or WhatsApp within three days to provide photos and videos of the product for confirmation and then ship it.

Customers are saying

4.99 ★ (1084)
Verified

Description


DC24V 90W ZD Zhongda Z5D90-24GU-30S Motor for Various Applications

Introducing the ZD Zhongda Z5D90-24GU-30S Motor, a reliable and efficient DC motor with a power rating of 90W. The ZD Zhongda Z5D90-24GU-30S is designed to meet various application needs, ensuring excellent performance and durability. With a voltage rating of DC24V, the ZD Zhongda Z5D90-24GU-30S Motor is ideal for automation projects and equipment that require precise motor control. Trust the ZD Zhongda Z5D90-24GU-30S for your motor needs and enjoy seamless operation in your systems.

Engineer's Quick Brief

  • 24V DC 90W geared motor platform designed for industrial automation, conveyor systems, vending equipment, packaging machinery, and compact motion control applications.
  • Z5D90-24GU-30S integrates a 90mm frame DC motor with GU-series gearbox compatibility, supporting multiple reduction ratios from 3:1 up to 200:1.
  • High torque output with low-speed stability makes this motor suitable for continuous-duty industrial transmission systems requiring compact installation space.

SEO Introduction

The ZD Zhongda Z5D90-24GU-30S is a 24V DC 90W geared motor widely used in industrial automation equipment, conveyor drives, vending systems, medical devices, compact transport mechanisms, and packaging machinery. The motor belongs to the Zhongda 90mm DC gear motor series and supports multiple gear reduction ratios through the GU-series gearbox platform.

Common industry search terms associated with this model include: 24V DC gear motor, 90W reduction motor, industrial geared motor, low RPM high torque motor, and Z5D90-24GU gearbox motor.

Technical Specifications

Parameter Specification
Model ZD Zhongda Z5D90-24GU-30S
Motor Type Brushed DC Gear Motor
Rated Voltage 24V DC
Rated Power 90W
No-load Speed 3300 RPM
Rated Speed (Motor) 2800 RPM
Rated Torque (Motor) 307 mN·m
Rated Current 5.0A
Brush Life Approx. 2000 Hours
Frame Size 90mm × 90mm
Gearbox Type GU Series Spur Gearbox
Supported Gear Ratios 3:1 to 200:1
Output Shaft Diameter 15mm
Lead Wire UL1015 AWG16
Lead Length 300mm ±10mm
Motor Weight Approx. 2.2kg
Gearhead Weight Approx. 1.5kg

Typical Gear Ratio Output Reference

Gear Ratio Approx. Output Speed Permissible Torque
10:1 280 RPM 2.24 N·m
30:1 93 RPM 6.04 N·m
50:1 56 RPM 10.1 N·m
100:1 28 RPM 18.1 N·m
200:1 14 RPM 20 N·m

Application Matrix

Industry Application Engineering Value
Packaging Equipment Conveyor drive systems Stable low-speed torque output
Vending Machines Product dispensing mechanisms Compact size with reliable transmission
Automation Systems Rotary positioning platforms Multiple reduction ratio flexibility
Medical Equipment Linear transfer modules Smooth DC motor operation
Logistics Machinery Sorting conveyors Continuous-duty performance

Koeed Gear Ratio Reference Tool




Troubleshooting & FAQ

Why is the motor speed lower than theoretical calculation?

Actual output speed is typically 2% to 20% lower than theoretical synchronous speed due to gearbox load conditions, friction losses, and applied torque demand.

Can the gearbox be replaced independently?

Yes. The GU-series gearbox is modular and can be replaced separately if shaft dimensions and reduction interfaces remain compatible.

What is the recommended power supply capacity?

A regulated 24V DC power supply with sufficient startup current margin is recommended. Continuous applications should consider transient inrush current conditions.

Is this motor suitable for continuous operation?

The motor is commonly used in continuous-duty industrial applications, but thermal management and load conditions should remain within rated specifications.

How is rotation direction changed?

Rotation direction can typically be reversed by swapping DC polarity connections on the motor terminals.

Cross-Reference & Selection

Cross-Reference Guide

  • Z5D90-24GU-30S belongs to the Zhongda 90mm 90W DC gear motor platform.
  • Compatible gearbox families include: 5GU□KB reduction gearheads.
  • Alternative voltage variants include: Z5D90-12GU and Z5D90-90GU.
  • Typical interchangeable industrial categories: 90mm 24V DC geared motors with 90W output and spur reduction gearbox architecture.
