Allen-Bradley 20F1AGC104JN0NNNNN — PowerFlex 753 AC Drive, 104A, 480V, Frame 5

AB · PowerFlex 753 · Air-Cooled Drive · NEW IN BOX · Ship from US

The 20F1AGC104JN0NNNNN is a frame 5 AC drive from the Allen-Bradley PowerFlex 753 family, rated 104A continuous at 480V three-phase (heavy duty) — roughly 50 HP (37 kW) heavy duty or 60 HP (45 kW) normal duty. It ships brand new, factory-sealed, from US warehouse stock, ready to integrate into a factory automation line without long lead times.

This catalog number decodes as 20F1A = PowerFlex 753 air-cooled, G = heavy duty, C = 480V 3-phase, 104 = 104A nominal, J = enhanced control, N = no brake, 0 = no HIM, NNNNN = no options. Send your BOM or replacement list to Moritta@KOEED.COM for a quote within 24 hours.

1. Key Technical Specifications & Overview

The PowerFlex 753 sits between the compact 525 and the high-power 755 in the AB drive lineup. It is the right choice when you need an air-cooled industrial drive with integrated EtherNet/IP for direct programming and monitoring from Allen-Bradley ControlLogix or CompactLogix controllers, but do not require liquid cooling or the larger frame-6–7 755 chassis.

2. Application Scenarios — Where the 20F1AGC104JN0NNNNN Fits

The 50 HP heavy-duty rating makes 20F1AGC104JN0NNNNN a workhorse for mid-power industrial loads. Common deployments include:

• Pumps and fans — centrifugal pump VFD control, HVAC supply / return fans, water-treatment aerators, mine dewatering.
• Conveyor systems — bottling lines, packaging lines, sortation, baggage handling, parcel hubs.
• Mixers, agitators and extruders — chemical blending tanks, plastic extrusion screws, food & beverage mixers where flux-vector torque control holds speed under varying load.
• Machine tool and CNC — spindle drives on lathes, milling spindles, surface grinders; pairs with Fanuc, Mitsubishi and Siemens CNC controllers in retrofit cells.
• Hoists, cranes and material handling — 200% / 3 s overload supports hoist braking and lift peaks; brake option can be added (catalog code B) if dynamic braking is needed.
• Water and wastewater — influent pumps, sludge handling, blower control; BACnet or EtherNet/IP integration to SCADA is straightforward.
• Mining and aggregate — feeder conveyors, crusher conveyors, dust-collection fans.

For lighter loads (under 25 HP) consider the 25B-D6P0N114 PowerFlex 525. For above-100 HP heavy-duty applications, step up to the PowerFlex 755. For Asian-spec machines built on Yaskawa, Omron, Panasonic or KEYENCE platforms, KOEED keeps equivalent drives and motion controllers in stock side by side.

3. Integration & Wiring Notes

Power wiring. Use the frame-5 power terminal block on the bottom of the drive. L1 / L2 / L3 are the 480V three-phase input; T1 / T2 / T3 feed the motor. Torque to the values on the drive nameplate label (typically 10–15 Nm for frame 5). Keep the motor cable short and use a VFD-rated cable with a continuous overall shield; ground the shield at both ends with 360° terminations to keep common-mode voltage off the motor bearings.

Control wiring. The 753 ships with a 24V DC control board, eight digital inputs, two analog inputs, two analog outputs, two relay outputs, and one PTC input. The catalog code J means enhanced control — it adds encoder / feedback support needed for true flux-vector closed-loop operation. If you ordered an encoder, wire it to the encoder port on the control board and configure parameters 80–90 for the PPR rating of your feedback device.

EtherNet/IP integration. The dual-port DLR (Device Level Ring) EtherNet/IP switch on the 753 main control board is the default path back to ControlLogix or CompactLogix via Studio 5000 / Logix Designer. Add a 20-750-ENETR module for dual-port ring topology, or 20-COMM cards for legacy DeviceNet, ControlNet, Profibus or BACnet. For Modbus RTU polling, the RS485 port on the drive speaks Modbus natively — frame checks with the KOEED Modbus CRC Calculator save commissioning time.

Braking. The N in position 9 means no brake IGBT. For high-inertia loads (hoists, extruders, crusher conveyors) you will need either a catalog code B unit (internal brake) plus an external braking resistor, or a separate regenerative supply. KOEED stocks 20F1AGC104JN0NNNNN as the base config; the brake / HIM / comm options can be quoted alongside.

Cross-platform note. If you are running a mixed fleet with Schneider Altivar, Yaskawa A1000 or Siemens Sinamics G120 drives, the EtherNet/IP backbone keeps the 753 on the same network. Use the KOEED PLC Error Code Database and AI Diagnostic Tool for fault decoding across brands.

4. Installation & Commissioning Tips

• Mounting clearance. Frame 5 needs at least 100 mm above and 50 mm below for airflow. The drive is air-cooled — keep cabinet inlet temperature below 50 °C and leave space for the heatsink to exhaust to a vented plenum or a cabinet fan.
• Input protection. Fit a branch-circuit disconnect, short-circuit protection (fuses or a circuit breaker sized to AB publication 750-IN006), and a line reactor if the supply impedance is below 1% or if multiple drives share a weak transformer.
• Grounding. Run a dedicated safety ground (PE) from the drive to the system ground bus. The motor frame should have its own bonding conductor back to the drive PE terminal — do not rely on the motor cable shield alone.
• First power-up. Before applying mains, verify the control board 24V supply is on, the HIM (if any) shows no fault, and motor parameters (amps, voltage, RPM, cos φ) match parameter 4xx. Run an autotune (static or rotating) to identify motor model. Verify encoder direction matches commanded direction if you are using flux-vector control.
• Programming. Use Connected Components Workbench (CCW) or Studio 5000 Logix Designer with the 753 AOP (Add-On Profile). The AOP exposes all parameters as tags in the controller, so you can read/write drive state from ladder or structured text.
• Commissioning tools. The KOEED PLC Analog Calculator speeds 4–20 mA scaling, and the PLC Hex to Float Converter helps decode feedback words from the drive over EtherNet/IP.
• Spare-parts pairing. If you are stocking a spare, common companion parts are 20-750-ENETR (EtherNet/IP option), 20-HIM-A6 (remote HIM), 20-750-DB1-D2 (DB resistor), and a 20-750-CB1 control board fan. Send the full BOM to Moritta@KOEED.COM to quote the kit in one shipment.

5. Procurement, Warranty & Lead Time

This listing is for a brand new, factory-sealed 20F1AGC104JN0NNNNN sourced through KOEED’s China sourcing network and shipped from US warehouse stock. The unit ships in original Allen-Bradley packaging with the factory QC checklist, CE / UL / cUL markings, and the AB serial-number label. The full manufacturer warranty applies.

Lead time for in-stock units is typically 3–5 business days for US destinations and 5–10 business days for international air freight. KOEED ships worldwide via DHL, FedEx and UPS, with full export documentation and a commercial invoice for customs. KOEED is an independent multi-brand distributor — not an OEM subsidiary of Rockwell Automation — and is part of a sourcing network that also covers Siemens, Mitsubishi, Fanuc, KEYENCE and the rest of the KOEED nine-brand portfolio (Omron, Schneider, Yaskawa, Panasonic).

Pricing is by RFQ only — send your part list, project name and target delivery to Moritta@KOEED.COM and KOEED will return availability, an FOB / EXW quote, and a freight estimate within 24 business hours. For multi-line BOMs the KOEED Create a Quote form is faster — upload the spreadsheet, add quantities, submit. KOEED also publishes recent transaction snapshots on the Real-Time Sales List for transparency on shipped part numbers.

Returns are accepted per the KOEED Return Policy; warranty claims are routed back through the manufacturer with KOEED coordinating the RMA. The Allen-Bradley 753 ships with traceability documents and full export paperwork. For hard-to-find variants of the 753 (different amp ratings, brake options, marine-class conformal coating, or matched 20-HIM-A6 / 20-750-ENETR kits) email Moritta@KOEED.COM directly with your specifications and the project context.
