NXL00165C2H1SSS0000 High-Performance Component

The NXL00165C2H1SSS0000 is a high-performance component designed for rigorous applications. With its robust construction and reliable performance, the NXL00165C2H1SSS0000 meets the demands of both consumer and industrial use. Its versatile design allows the NXL00165C2H1SSS0000 to fit into various configurations seamlessly, making it a preferred choice for engineers and technicians.

Engineer's Quick Brief

  • Industrial Vector Control Performance: Engineered for 3-phase 380V-500V mains grids, supplying a 16A continuous current layout optimized for severe variable torque and heavy-duty constant torque motor processes.
  • Compact IP21 Frame Architecture: Features an integrated H1 space-saving structural footprint with built-in RFI filters and brake choppers, eliminating external panel enclosure overheads.
  • Advanced PID & Multi-Pump Control: Incorporates localized application software configurations enabling seamless closed-loop tracking for industrial fan stations, booster pump matrices, and conveyor systems.

Vacon NXL00165C2H1SSS0000 Compact AC Frequency Converter

The Vacon NXL00165C2H1SSS0000 is an enterprise-tier, highly intelligent AC frequency converter (variable speed drive) manufactured by Danfoss Vacon to govern dynamic speed loops on induction motors. Operating within a high-spec supply matrix of 380V to 500V AC, this 16A vector control drive outputs up to 7.5 kW (10 HP) under standard industrial low-overload conditions. The specific alphanumeric code defines a fully packed automation component complete with an alpha-numeric display keypad unit, IP21 enclosure rating, size H1 chassis integration, and standard software macros. Designed for modern machine builders and plant maintenance teams, the NXL series delivers tightly regulated velocity loops and high open-loop start torques across demanding material handling networks and continuous chemical flow lines.

Technical Specifications

Electrical & Mechanical Parameter Technical Specification Value
nt_1Brand / Manufacturer Danfoss Vacon (Finland)
Product Model Code NXL00165C2H1SSS0000
Core Architecture Series Vacon NXL Compact Series
Rated Mains Input Voltage 3-Phase 380V to 500V AC (+10% / -15% Input Tolerance)
Input Frequency Capability 50 / 60 Hz (Operational Range: 45 to 66 Hz)
Continuous Output Current (I_L) 16.0 Amperes (Low Overload Capacity Profile)
Heavy-Duty Output Current (I_H) 11.0 Amperes (High Overload Capacity Profile - 150% torque)
Typical Shaft Motor Power Low Overload: 7.5 kW (10 HP) | High Overload: 5.5 kW (7.5 HP)
Enclosure Mechanical Protection IP21 / Type 1 (Integrated Interior Vent Grids)
Control Interface Display Character-based LCD Control Keypad Panel (C-Type)
Physical Framework Dimension Chassis Size H1 Layout Matrix
Internal Dynamic Braking Built-in Brake Chopper Transistor Unit Included
EMC Compliance RFI Filter Integrated H-Level Filter (Meets EN61800-3 Environment 1 Class H)

Application Matrix & Quality Control Scenarios

Industrial Quality Scene Tracking & Control Challenge Metrology Operational Advantage
Commercial HVAC Ventilation Fans Adjusts volumetric air currents dynamically via standard differential temperature transmitters. Built-in sleep mode and resonance frequency skipping suppress motor hum and cut power draw.
Booster Pump Pressure Loops Maintains uniform industrial pipe network fluid dynamics without hydraulic pressure spikes. The integrated internal PID controller processes 4-20mA sensor signals directly, removing PLC dependencies.
Automated Factory Conveyor Belts Requires constant torque delivery at lower frequencies during heavy bulk loading cycles. Open-loop sensorless vector control yields steady, linear motor torque profiles under changing mechanical load weight.

Quick Insights: Vacon NXL00165 Environmental Derating & Motor Protection Tool

For Control Panel Designers & Site Electrical Engineers: Input your field deployment limits to accurately calculate variable frequency drive current deratings and determine required electronic thermal protection benchmarks.

Commissioning & Drive Troubleshooting FAQ

Q1: What parameters govern basic motor data entry within the Vacon NXL control panel?

A1: Prior to engaging running cycles, configure the primary motor nameplate values inside Group 1 Parameters. Navigate via the LCD display to configure **P1.1 (Motor Nominal Voltage)**, **P1.2 (Motor Nominal Frequency)**, **P1.3 (Motor Nominal Speed)**, and crucially **P1.4 (Motor Nominal Current)** set to match the specific motor field wiring structure. Misconfiguring P1.4 compromises the drive's built-in electronic thermal software tracking protection.

Q2: How do I address a persistent "F1 Overcurrent" trip code during high inertia motor acceleration?

A2: An F1 trip code signifies the drive's hardware protection has detected an output amperage surge crossing safe limits. If this occurs on startup, increase the acceleration ramp profile setting via **P1.13 (Acceleration Time)** to lengthen the ramp duration. Alternatively, examine the system mechanical coupling for binding or check parameter **P1.10 (Torque Boost)**; if manual boost curves are set too high, localized core saturation can generate sudden current spikes.

Q3: Why does the drive display an "F9 Undervoltage" fault code while the machine sits in a static ready state?

A3: The F9 code indicates internal intermediate DC bus voltages have dropped below the safe threshold level (typically under 333V DC for 500V systems). Measure incoming line phases L1, L2, and L3 with a multimeter to verify line stability. If the supply grids are balanced, a static F9 fault can stem from a degrading internal pre-charge relay or aged electrolytic filtering capacitor matrices within the main power board assembly.

Cross-Reference Guide

The Vacon NXL00165C2H1SSS0000 is built around standard global industrial standard metrics. When handling production retrofits or replacing discontinued legacy hardware lines, verify equivalent performance frames against the following platform variations:

Equivalent Series Configurations Interchange Configuration Status Critical Hardware Verification Details
Danfoss VLT AutomationDrive FC302 Series (7.5 kW) Functional Portfolio Migration Alternative Upgrading to modern FC302 frames expands fieldbus capacity. Re-verify physical enclosure size adjustments and terminal block mapping loops.
Vacon V00165 AC Drive Variant Series Internal Family Suffix Alignment Match Ensure equivalent frame structures match the IP21 casing layout and size H1 parameters to maintain line dimensions.
