ABL8RPS24050


Price:
Sale price$148.00 USD

Due to the constant fluctuations in product information, we kindly ask you to contact us before making a purchase to confirm the latest price before placing an order.

  • Business Days Only (Monday through Saturday)
Contact us By email Chat on WhatsApp
safe

Schneider Electric ABL8RPS24050 Switching Power

Product range: Phaseo
Product Type: Power
Power type: adjust switch mode
Input voltage:
100...120 V AC single phase, terminal: N-L1
200...500 V AC phase line to phase line, terminal: L1-L2
Output voltage: 24 V DC
Rated power [W] : 120 W
Attached equipment: Power factor correction filter in accordance with IEC 61000-3-2
Power output current: 5 A
Output protection type:
Anti-overload, optical power : manual or automatic reset
Overvoltage prevention, optical power : 30...32 V, manual reset
Short circuit, optical power : manual or automatic reset
Anti-undervoltage, optical power: tripping if U < 21.6 V
Thermal, optical power : automatic reset
Ambient temperature: 50...60 °C
-25...50 °C no
Input voltage limit: 170...550 V
85...132 V
Network frequency: 47...63 Hz
Maximum inrush: 30 A for 2 ms
Power factor correction:
0.51 on... 240 V
0.59 on... 120 V
Power: 87%
Output voltage limit: 24...28.8 V adjustable
Power consumption W: 15.5 W
Line and load regulation: 1...3 %
Hold time:
>= 120 ms on ... 400 V
>= 20 ms on ... 100 V
>= 40 ms on... 240 V
Allowable temporary boost current: 1.5 x In for 4 seconds
Wiring ability:
Screw type terminal Applicable Input wiring, connection capacity: 3 x 0.5...3 x 4 mm2 AWG 22...AWG 12
Screw type terminal Applicable Input ground connection, connection capacity: 1 x 0.5...1 x 4 mm2 AWG 22...AWG 12
Screw type terminal Applicable Output wiring, connection capacity: 4 x 0.5...4 x 4 mm2 AWG 22...AWG 12
Screw type terminal Applicable Output ground connection, connection capacity: 1 x 0.5...1 x 4 mm2 AWG 22...AWG 12
Removable screw terminal block For diagnostic relays, connection capacity: 2 x 2.5 mm2
Logo: CE
Installation method:
35 x 15 mm symmetrical DIN rail
35 x 7.5 mm symmetrical DIN rail
Operating position: vertical
Working elevation: 2000 m
Output coupling: parallel series
Test name:
Harmonic current radiation in accordance with EN/IEC 61000-3-2
Conducted radiation on the power line in accordance with EN 55022 Category B
Electrostatic discharge in accordance with EN/IEC 61000-4-2
Induced electromagnetic field in accordance with EN/IEC 61000-4-6
Magnetic field in accordance with EN 61000-4-8
Main socket conforms to IEC 61000-4-11
Propagating electromagnetic field in accordance with EN/IEC 61000-4-3
Propagation radiation in accordance with EN 55022 Category B
Fast transients in accordance with IEC 61000-4-4
Surge in accordance with EN/IEC 61000-4-5
LED status:
LED Green and Red Applicable Output Voltage
LED green, red and orange Applicable Output current
Depth: 125 mm Height: 143 mm Width: 56 mm
Product weight: 0.7 kg
