BMXDDI1602


Price:
Sale price$124.20 USD

Due to the constant fluctuations in product information, we kindly ask you to contact us before making a purchase to confirm the latest price before placing an order.

  • Business Days Only (Monday through Saturday)
Contact us By email Chat on WhatsApp
safe
Main
range of product
Modicon X80

product or component type
Discrete input module

discrete input number
16

discrete input type
Isolated

input type
Current sink (logic positive)

discrete input voltage
24 V DC positive

discrete input current
3.5 mA

input compatibility
With 2-wire/3-wire proximity sensors conforming to IEC 60947-5-2

Complementary
sensor power supply
19...30 V

voltage state 1 guaranteed
>= 11 V

current state 1 guaranteed
>= 2 mA

voltage state 0 guaranteed
<= 5 V

current state 0 guaranteed
<= 1.5 mA

input impedance
6800 Ohm

insulation resistance
> 10 MOhm 500 V DC

power dissipation in W
<= 2.5 W

DC typical filtering time
4 ms

DC maximum filtering time
7 ms

paralleling of inputs
Yes

typical current consumption
90 mA at 3.3 V DC

MTBF reliability
798237 H

protection type
Reverse polarity protection
1 external fuse per group of channel 0.5 A fast blow

voltage detection threshold
< 14 V DC sensor fault
> 18 V DC sensor OK

status LED
1 LED green module operating (RUN)
1 LED per channel green channel diagnostic
1 LED red module I/O
1 LED red module error (ERR)

product weight
0.25 lb(US) (0.115 kg)

Environment
directives
2012/19/EU - WEEE directive
2014/30/EU - electromagnetic compatibility
2014/35/EU - low voltage directive

IP degree of protection
IP20

product certifications
CE
CSA
UL
RCM
Merchant Navy
EAC

standards
EN 61000-6-2
EN 61000-6-4
EN 61131-2
EN 61010-2-201

dielectric strength
1500 V AC at 50/60 Hz 1 minute, primary/secondary

vibration resistance
3 gn

shock resistance
30 gn

ambient air temperature for storage
-40...185 °F (-40...85 °C)

ambient air temperature for operation
32...140 °F (0...60 °C)

relative humidity
5...95 % without condensation 131 °F (55 °C)

protective treatment
TC

operating altitude
0...6561.68 ft (0...2000 m)
2000...5000 m (with derating factor)
