Pan-Globe P909X-702-010-000AX Temperature Controller - 1PC

Pan-Globe P909X-702-010-000AX Temperature Controller - 1PC

$403.23 USD
$403.23 USD $403.23 USD
Sale Sold out
Shipping calculated at checkout.
MPN P909X702010000AX
type Temperature Controller
weight 0.5 kg
output_type Relay
model P909X-702-010-000AX
quantity 1
sensor_type Thermocouple
display_type Digital
power_supply AC 100-240V
temperature_range -50 to 120 °C
size 100 x 75 x 30 mm
