Allen Bradley 20F11RC015JA

Allen Bradley 20F11RC015JA

$3,087.53 USD
$3,087.53 USD $3,087.53 USD
Sale Sold out
Shipping calculated at checkout.
MPN 20F11RC015JA0NNNNN
Model 20F11RC015JA
Power 20Ft-A
Control_Panel 11RC015JA
View full details

  • step 1: Quote Or Shop Now

    You can place an order directly or contact us via email and whatsapp for a quote

  • step 2: Confirmation and delivery

    After placing an order, we will contact you by email or WhatsApp within three days to provide photos and videos of the product for confirmation and then ship it.

Customers are saying

4.99 ★ (1084)
Verified

Description


Allen Bradley 20F11RC015JA

The Allen Bradley 20F11RC015JA is a compact industrial control panel designed for use in harsh environments. It features a robust construction and advanced monitoring capabilities. The panel includes a 11RC015JA control module, which provides essential functions for industrial automation. The 20Ft-A rating indicates its reliability and durability in demanding applications.

Engineer's Quick Brief

  • Robust Multi-Control Architecture: Supports V/Hz control, Sensorless Vector Control (SVC), and precise Vector Control with FORCE Technology to handle demanding variable torque and constant torque industrial applications.
  • Optimized Standard Hardware Profile: Engineered within the compact PowerFlex 753 Frame structure featuring an integrated DC Link Choke to mitigate harmonic distortions without expanding enclosure space requirements.
  • Seamless Automation Integration: Embedded with localized I/O alongside expandable option slots for dual-port EtherNet/IP, DeviceNet, or Profibus modules, reducing field commissioning downtime in pumping, conveyor, and fan systems.

Allen-Bradley PowerFlex 753 AC Drive Overview

The Allen-Bradley 20F11RC015JA is a high-performance PowerFlex 753 AC Drive manufactured by Rockwell Automation. Configured for 3-Phase 400V AC operating environments, this industrial variable frequency drive (VFD) delivers a rated continuous output current of 15.4 Amps. Optimized for versatile motor speed regulation, it excels in managing heavy-duty machinery profiles through complex sensorless vector algorithm structures. Built into an IP20/Open Type wall-mount enclosure frame, it offers the ideal balance of precise torque control, embedded safety functionalities, and global regulatory compliance for enterprise industrial automation.

Technical Specifications

Specification Parameter Category Detailed Technical Operational Values
Manufacturer / Brand Allen-Bradley / Rockwell Automation
Product Series PowerFlex 753 Variable Frequency Drives
Catalog Part Number 20F11RC015JA
Input Voltage Rating 3-Phase, 400V AC / 540V DC (±10% operational tolerance)
Rated Continuous Output Current 15.4 Amps
Nominal Operational Power (ND) 7.5 kW / 10 Horsepower (Normal Duty Configuration)
Nominal Operational Power (HD) 5.5 kW / 7.5 Horsepower (Heavy Duty Configuration)
Enclosure Protection Class IP20 / NEMA Open Type (Flange/Wall Mount Structure)
Built-In Filtering / Filtering Circuit Integrated EMC Filtering with Internal DC Link Choke
Control Modes Available Volts-per-Hertz (V/Hz), Sensorless Vector Control (SVC)

Industrial Application Matrix

Target Deployment Field Applicable Machine Load Type System Engineering Value Realized
Material Handling Systems Heavy-Duty Distribution Conveyors & Sorters High starting torque curves manage mechanical friction and sudden shock load transitions efficiently.
Water & Wastewater Treatment Centrifugal Pumps & Submersible Aerators Implements customized acceleration/deceleration S-curves to suppress harmful water hammer effects.
HVAC & Building Facilities Industrial Air Handling Fans & Exhaust Units Utilizes energy-efficient quadratic variable torque modes to lower plant-wide electrical utility demands.

Koeed Field FAE Tool: PowerFlex 753 Fault & Motor Setup Calculator

Accelerate on-site commissioning procedures. Use the interactive panel below to instantly query common Rockwell PowerFlex 750-Series hardware fault codes or estimate nominal AC induction motor parameters.

1. Interactive Hardware Fault Diagnostic Lookup

2. Synchronous Motor Speed & Slip Calculator

Theoretical Synchronous Speed: 1500 RPM

Calculated Rotor Slip Percentage: 4.0%

Field Commissioning & Troubleshooting Guide

Q: What parameters are mandatory for initial motor startup during commissioning?

To complete a basic startup routing on the PowerFlex 753, you must program the core values found within the Motor Nameplate Group via the Human Interface Module (HIM) or Connected Components Workbench (CCW) software:

  • Parameter 25: Motor Nameplate Amps (Set matching nominal current).
  • Parameter 26: Motor Nameplate Volts (Typically 400V for this unit).
  • Parameter 27: Motor Nameplate HP/kW (Typically 5.5 kW / 7.5 kW).
  • Parameter 28: Motor Nameplate Frequency (50Hz / 60Hz standard).

Following value validation, execute a Direction Test and Autotune routing (Parameter 70) to dynamically map internal stator resistance vectors.

Q: How does the internal DC Link Choke improve system performance?

The 20F11RC015JA architecture includes a built-in DC Link Choke. This integrated component functions as a continuous low-pass filter on the rectified DC bus line. It reduces total harmonic distortion (THD) mirrored back to the supply transformers, improves input power factor metrics, and shields internal sensitive rectifier diodes from high-energy line spikes without requiring a separate bulky external AC line reactor.

Q: Can this drive support Safe Torque Off (STO) safety integration?

Yes, the PowerFlex 753 frame structure supports native safety expansion. While base platforms require a hardware choice configuration, engineers can populate specialized expansion slot lanes with a 20-750-S Safe Torque Off option module or a 20-750-S1 Safe Speed Control card, ensuring immediate compliance with SIL3, PLe Category 3 / 4 functional emergency machinery infrastructure safeguards.

Cross-Reference Guide

The PowerFlex 753 catalog configuration 20F11RC015JA is dimensionally compatible or can be substituted as a direct modular integration alternative for these system profiles:

  • PowerFlex 755 Step-Up Alternative: 20G11RC015JA (Upgrades system interface with native on-board EtherNet/IP processing engines).
  • Legacy Series Replacement: Replaces typical Allen-Bradley PowerFlex 70 / PowerFlex 700 series drive footprints with identical current output load ratings (verify overall chassis width sizing specs).
  • Cross-Brand Functional Alternative: Schneider Electric Altivar ATV340U75N4 / Siemens SINAMICS G120 Series drives with matching 15.4 Amp output vectors (requires updating automation communication register mappings).
